TW 95 Schaeff Excavator Specs & Dimensions - (2017 - 2026)

Manufactured by Schaeff, this is the TW 95 wheel excavator. Find and download detailed specs and data sheets for this machine here…

Manufactured by Schaeff, this is the TW 95 wheel excavator. Find and download detailed specs and data sheets for this machine here.

The Schaeff TW 95 is a 9.1t machine with Deutz engine which powers this model with up to 74.4kW or 99 horse power. The TW 95 is categorised in the smallest machine segment in the wheel excavators category. The TW 95’s size is 2.45m x 6.5m x 2.93m. The bucket of TW 95 has a capacity of 0.127m³ which is average for this type of machine.

Since 2017, this model has included Overload alert, Quick hitch mech. And Blade. Material Handling Excavator, Quick hitch hydr. And Diesel particulate filter are not provided on this model as of 2017. There are more detailed specifications and machine descriptions available in the original Schaeff TW 95 specs data sheet. Specification sheet is available for a free download in English, French and German - providing the machine descriptions and more detailed specs about this particular model.

This model can be acquired for a list price between €140000 and €178000. Production of the TW 95 continues in 2017. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

The most commonly viewed Schaeff models of this type on LECTURA Specs are the TW 95, TW 75 and TW 110, and 3 other wheel excavators, which currently range from 7.4t up to 11t are also available. This TW 95 wheel excavator, which has been in production between 2017 and 2017 ranks in the LECTURA index at #113. Want more detailed specifications? Download the latest Schaeff TW 95 specs data sheet on LECTURA Specs today!

Wheel Excavators Schaeff TW 95
Wheel Excavators Schaeff TW 95
Wheel Excavators Schaeff TW 95
Wheel Excavators Schaeff TW 95
Wheel Excavators Schaeff TW 95
Wheel Excavators Schaeff TW 95
Wheel Excavators Schaeff TW 95
Wheel Excavators Schaeff TW 95
Wheel Excavators Schaeff TW 95
Wheel Excavators Schaeff TW 95

Technical specs - TW 95 Schaeff

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
9.1 t
Standard tyres
8.25-20
Bucket capacity
0.127 m³
Boom
MB
Outrigger stabilisers
2 2/4-fold
Transport length
5.43 m
Transport width
2.45 m
Transport height
2.93 m
Max. Reach horizontal
8 m
Dredging depth
4 m
Tear-out force
42.6 kN
Bucket width
0.4 m
Travel speed
20 km/h
Engine manuf.
Deutz
Engine type
TCD3.6 L4
Engine power
74 kW
Displacement
3.6 l
Revolutions at max torque
1600 rpm
No. of cylinders
4
Emission level
V/Tier 4 f

More technical details, like: bucket capacity min., bucket capacity max., dipper length, turning radius inside, turning radius outside, model series, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Blade
No
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
No
Track guidance
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
Yes

Download datasheets (PDF)

Schaeff TW 95 FAQ

When was the Schaeff TW 95 manufactured?

The Schaeff TW 95 was first produced in 2017.

How much does the Schaeff TW 95 wheel excavator weigh?

The Schaeff TW 95 wheel excavator weighs 9.1 tons.

What are the transport dimensions of the Schaeff TW 95 wheel excavator?

The Schaeff TW 95 has a transport length of 5.43 meters, a transport width of 2.45 meters, and a transport height of 2.93 meters.

What is the travel speed of the Schaeff TW 95 wheel excavator?

The Schaeff TW 95 has a travel speed of 20 km/h.

What are the undercarriage specifications of the Schaeff TW 95 wheel excavator?

The Schaeff TW 95 has standard tyres sized 8.25-20 and 2 outrigger stabilisers (2/4-fold).

What are the excavation performance specifications of the Schaeff TW 95 wheel excavator?

The Schaeff TW 95 wheel excavator has a dredging depth of 4 meters, a maximum horizontal reach of 8 meters, and is equipped with a monobloc boom.

What is the tear-out force of the Schaeff TW 95 wheel excavator?

The Schaeff TW 95 wheel excavator has a tear-out force of 42.6 kN.

What are the bucket specifications of the Schaeff TW 95 wheel excavator?

The Schaeff TW 95 has a bucket capacity of 0.127 cubic meters and a bucket width of 0.4 meters.

How much is a Schaeff TW 95 Wheel excavator (2017u20132025) worth?

The residual value of the Schaeff TW 95 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
