A 910 Compact Litronic Liebherr Excavator Specs & Dimensions - (2017 - 2020)

Performance

Liebherr wheeled excavators have the performance to get building work done faster. High load capacity with the best ranges in its class, combined with the short rear slewing radius, delivers extraordinary productivity and flexibility in use. More performance for greater efficiency. Liebherr compact wheeled excavators are used on building sites all over the world, where they embody force and speed combined with compact dimensions. Using them, machine operators achieve impressive levels of performance, day-in and day-out. Whether on inner city building sites, in roadway construction, classic earthmoving, or for digging trenches and laying pipes, more can be achieved faster with Liebherr compact wheeled excavators.

Efficiency

Liebherr compact wheeled excavators are machines that combine high productivity and compact flexibility with excellent levels of economy - and all this comes as standard from the factory. On request, the efficiency of each wheeled excavator can be boosted further with a Liebherr productive bucket, a fuel-saving Liebherr hydraulic oil, or a Liebherr quick coupling system. For more return from each operating hour.

Increased Utilisation

The fully hydraulic Liebherr LIKUFIX quick coupling system increases the utilisation of a wheeled excavator by 30% on average. The construction process is accelerated, and orders are completed faster, enabling more turnover to be achieved per machine.

Efficiency

The A 910 Compact Litronic sets the standard in its class for fuel efficiency and travel performance. The newly developed Deutz diesel engine meets the requirements of exhaust stage IIIB, even without the use of a particle filter. Emissions and operating costs are kept at a low level.

Hydraulic oils with added value

Liebherr hydraulic oils achieve a service life of 6,000 operating hours and more. Instead of having defined change intervals, the results of the oil analysis (every 1,000 operating hours or after one year) determine when the oil needs to be changed. The unique Liebherr Hydraulic Plus oil can even achieve a service life of 8,000 operating hours and more - at the same time as reducing fuel consumption by up to 5%.

Comfort

The newly developed Liebherr operator’s cab offers the machine operator the necessary space and comfort to make optimum use of the machine’s performance. The operator seat offers the following features as standard, amongst others: air suspension, seat heating and lumbar support. Greater comfort for higher performance. The modern Liebherr operator's cab is the largest in this machine class, and offers the best preconditions for healthy, concentrated and productive working. The features which make this possible include the standard feature of an air-sprung operator seat with seat heating, the automatic air conditioning and the ergonomically arranged control elements with touchscreen indicating unit. One example of the extensive safety equipment is the roll-over protection system (ROPS) for the cab fitted as standard according to ISO 12117-2 as well as the standard bulletproof roof glass panel.

An advance in comfort and convenience

The automatic air conditioning offers convincingly intuitive operation. Temperature, blower setting and the various air nozzles in the head, chest and foot areas are set using the touch screen on the indicating unit. The defrost/defog one-button function clears fogged up windows in the shortest possible time. The filter for the cab air can be changed easily and conveniently from the outside.

Operator seats

The Standard, Comfort and Premium operator seat versions that are available have recognized orthopedic properties, and offer sitting comfort at the highest level. Even the standard operator seat offers an extensive range of standard features such as air suspension, seat heating, headrest, lumbar support and many more besides.

Reliability

Hydraulic components, electronic components, swing ring, swing drive and steel structure: developed, tested and produced by Liebherr. This produces the high quality you have come to expect, for a long service life and maximum machine availability. Greater quality for higher reliability.

Power, speed and precision

The intelligent design of the uppercarriage ensures high grab forces despite a rear slewing radius of just 1.60 m. Fast, precise release of material even in hard soil ensures maximum productivity. Performance and flexibility for every building site. The engine’s power has been drastically increased to provide more acceleration and better handling, particularly on gradients. In drive mode the full engine power is available when the joystick is deactivated. The machine’s speed can be adjusted to various types of use by simply using the MODE switch. More productivity due to reduced driving time. The exceptional sensitivity of the hydraulic system allows precise working at high speeds, and with movements in parallel. This means the machine operator can carry out the most challenging tasks in a short time, not only at reduced speed but also with maximum performance of the machine. The optional Liebherr proportional control provides additional comfort for sensitive, precise control using the two-way mini-joystick.

Durability and innovation

Key components such as hydraulic components, electronic components, swing ring and swing drive are developed, tested and produced by Liebherr itself. The significant depth of production ensures the highest quality and permits optimum coordination of components. The high-quality Liebherr components are also used in many other sectors and products.

Service

A fast response when service is required minimises downtime and ensures that schedules can be met. This is made possible by a spare part availability rate in excess of 98% and a 24 h delivery service for spare parts. Service engineers trained by Liebherr carry out service and maintenance work on the spot, quickly and in accordance with the manufacturer's specifications.

Lift Capacities with Two-piece Boom 2.10 m

The lift capacities on the load hook of the Liebherr quick coupler 33 without working tool are stated in metric tons (t) and are valid on a firm, level supporting surface with blocked oscillating axle. These capacities can be slewed through 360° with the undercarriage in the transverse position. Capacities in the longitudinal position of the undercarriage (+/- 15°) are specified over the steering axle with the stabilizers raised and over the rigid axle with the stabilizers down. The values apply when the adjusting cylinder is in the optimal position. Indicated loads comply with the ISO 10567 standard and do not exceed 75 % of tipping or 87 % of hydraulic capacity, or are limited by the permissible load of the load hook on the quick coupler (max. 5 t). Without the quick coupler, lift capacities will increase by up to 110 kg. In accordance with the harmonised European Standard EN 474-5, hydraulic excavators used for lifting operations must be equipped with pipe fracture safety valves, an overload warning device, a load hook and a lift capacity chart.
