HMK 140 W Hidromek Excavator Specs & Dimensions - (2009 - 2010)

Hidromek is the manufacturer of the wheel excavator model HMK 140 W. Find and download detailed specs and data sheets for this mac…

Hidromek is the manufacturer of the wheel excavator model HMK 140 W. Find and download detailed specs and data sheets for this machine here.

This wheel excavator is built to provide up to 98kW or 131 horse power, delivered from its powerful Mitsubishi engine to the 16.2t HMK 140 W machine. The HMK 140 W is categorised in the medium sized machine segment in the wheel excavators category. The HMK 140 W’s size is 2.5m x 8.35m x 3.99m. The bucket capacity of HMK 140 W is 0,6m³, which is above average for this type of machine.

The Hidromek HMK 140 W has been equipped and sold with Material Handling Excavator, Cabin adjustment and Blade. It has been sold without air Track guidance, Quick hitch hydr. And Quick hitch mech. As of 2010. There are more detailed specifications and machine descriptions available in the original Hidromek HMK 140 W specs data sheet. Specification sheet is available for a free download in English and Spanish - providing the machine descriptions and more detailed specs about this particular model.

This model can be acquired for a list price between €88000 and €112000. Production of the HMK 140 W stopped in 2010. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

Hidromek currently produces 2 other wheel excavators, which range from 15.7t up to 22.1t - the most visited on LECTURA Specs are HMK 200 W, HMK 140 W. Want more detailed specifications? Download the latest Hidromek HMK 140 W specs data sheet on LECTURA Specs today!

Visit Hidromek live at

HMK 140 W

Years of manufacture: 2009—2010

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
Events
News

Technical specs - HMK 140 W Hidromek

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 16.2 t

Standard tyres: 10.00-20 14PR

Bucket capacity: 0.6 m³

Boom: MB

Outrigger stabilisers: 2/4 2/4-fold

Transport length: 8.35 m

Transport width: 2.5 m

Transport height: 3.99 m

Max. Reach horizontal: 8.4 m

Dredging depth: 4.7 m

Tear-out force: 11 kN

Bucket width: 0.75 m

Travel speed: 27 km/h

Model series: HMK

Engine manuf.: Mitsubishi

Engine type: 4 M 50 TL

Engine power: 98 kW

Displacement: 4.9 l

Revolutions at max torque: 1600 rpm

More technical details, like: bucket capacity min., bucket capacity max., dipper length, turning radius inside, turning radius outside, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter: No
Blade: Yes
Cabin adjustment: Yes
Overload alert: Yes
Material Handling Excavator: Yes
Track guidance: No
Aircondition: Yes
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Hidromek HMK 140 W FAQ

When was the Hidromek HMK 140 W manufactured?

The Hidromek HMK 140 W was manufactured from 2009 to 2010.

How much does the Hidromek HMK 140 W weigh?

The Hidromek HMK 140 W weighs 16.2 tons.

What are the transport dimensions of the Hidromek HMK 140 W wheel excavator?

The transport dimensions of the Hidromek HMK 140 W are 8.35 meters in length, 2.5 meters in width, and 3.99 meters in height.

What is the travel speed of the Hidromek HMK 140 W wheel excavator?

The Hidromek HMK 140 W has a travel speed of 27 km/h.

What are the undercarriage specifications of the Hidromek HMK 140 W wheel excavator?

The Hidromek HMK 140 W is equipped with standard tyres sized 10.00-20 14PR and features 2/4-fold outrigger stabilisers.

What are the excavation performance specifications of the Hidromek HMK 140 W wheel excavator?

The Hidromek HMK 140 W has a dredging depth of 4.7 meters, a maximum horizontal reach of 8.4 meters, and is equipped with a monobloc boom.

What is the tear-out force of the Hidromek HMK 140 W wheel excavator?

The Hidromek HMK 140 W wheel excavator has a tear-out force of 11 kN.

What are the bucket specifications of the Hidromek HMK 140 W wheel excavator?

The Hidromek HMK 140 W has a bucket capacity of 0.6 cubic meters and a bucket width of 0.75 meters.

How much is a Hidromek HMK 140 W Wheel excavator (2009u20132010) worth?

The residual value of the Hidromek HMK 140 W depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
