HMK 200 W Hidromek Excavator Specs & Dimensions - (2011 - 2020)

The HMK 200 W wheel excavator model is manufactured by Hidromek. Find and download detailed specs and data sheets for this machine…

The HMK 200 W wheel excavator model is manufactured by Hidromek. Find and download detailed specs and data sheets for this machine here.

The Hidromek HMK 200 W is a 22.15t machine with Isuzu engine which powers this model with up to 120.7kW or 161 horse power. This Hidromek wheel excavator belongs to the biggest machine segment in the wheel excavators category. The HMK 200 W’s size is 2.5m x 9.66m x 3.35m. The bucket capacity of HMK 200 W is 0.9m³, which is above average for this type of machine.

The Hidromek HMK 200 W has been equipped and sold with Aircondition, Quick hitch hydr. And Blade. Material Handling Excavator, Quick hitch mech. And Diesel particulate filter are not provided on this model as of 2017. There are more detailed specifications and machine descriptions available in the original Hidromek HMK 200 W specs data sheet.

This model can be acquired for a list price between €121000 and €155000. Production of the HMK 200 W continues in 2017. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

The most commonly viewed Hidromek models of this type on LECTURA Specs are the HMK 140 W, and 1 other wheel excavators, which currently range from 15.7t up to 15.7t are also available. Ranked in the LECTURA index at #118, this HMK 200 W wheel excavator has models that date from 2011 to 2017. Want more detailed specifications? Download the latest Hidromek HMK 200 W specs data sheet on LECTURA Specs today!

Wheel Excavators Hidromek HMK 200 W
Wheel Excavators Hidromek HMK 200 W
Wheel Excavators Hidromek HMK 200 W
Wheel Excavators Hidromek HMK 200 W
Wheel Excavators Hidromek HMK 200 W
Wheel Excavators Hidromek HMK 200 W
Wheel Excavators Hidromek HMK 200 W
Wheel Excavators Hidromek HMK 200 W
Wheel Excavators Hidromek HMK 200 W
Wheel Excavators Hidromek HMK 200 W
Wheel Excavators Hidromek HMK 200 W
Wheel Excavators Hidromek HMK 200 W
Wheel Excavators Hidromek HMK 200 W
Wheel Excavators Hidromek HMK 200 W

Visit Hidromek live at

Technical specs - HMK 200 W Hidromek

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
22.1 t
Standard tyres
10.00-20 16 PR
Bucket capacity
0.9 m³
Boom
MB
Outrigger stabilisers
2/4 2/4-fold
Transport length
9.66 m
Transport width
2.5 m
Transport height
3.57 m
Max. Reach horizontal
9.39 m
Dredging depth
5.79 m
Tear-out force
142.19 kN
Bucket width
1.11 m
Travel speed
30 km/h
Model series
HMK
Engine manuf.
Isuzu
Engine type
AI 4 HK 1 X
Engine power
128 kW
Displacement
5.193 l
Revolutions at max torque
1500 rpm
Max. torque
674 Nm
No. of cylinders
4
Cylinder bore x stroke
115x125 mm
Emission level
III A / Tier 3

More technical details, like: bucket capacity min., bucket capacity max., dipper length, turning radius inside, turning radius outside, dimension lxwxh, number of mono booms, total number of dippers - mono, engine manufacturer, engine model, rated speed, engine output - net...

More technical details, like: bucket capacity min., bucket capacity max., dipper length, turning radius inside, turning radius outside, dimension lxwxh, number of mono booms, total number of dippers - mono, engine manufacturer, engine model, rated speed, engine output - net, transmission type, number of tyres - standard, tyre size - standard, maximum transport length - mono boom, transport height - over mono boom, overall width, machine width - maximum, wheelbase, rear axle to slew centre, tailswing radius, cab height, ground clearance, overall width - stabilisers down, mono boom size, standard dipper length, longest dipper length, ground level reach - mono boom, maximum dig height - mono boom, dump clearance height - mono boom, dig depth - mono boom, fuel tank, slew speed, max bucket breakout, mono boom, number of main pumps, main pumps - maximum flow, boom pressure, operating weight are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Blade
Yes
Cabin adjustment
Yes
Overload alert
Yes
Material Handling Excavator
Yes
Track guidance
No
Aircondition
Yes
Quick hitch hydr.
Yes
Quick hitch mech.
No

Download datasheets (PDF)

Hidromek HMK 200 W FAQ

When was the Hidromek HMK 200 W manufactured?

The Hidromek HMK 200 W was manufactured from 2011 to 2020.

How much does the Hidromek HMK 200 W weigh?

The Hidromek HMK 200 W weighs 22.1 tons.

What are the transport dimensions of the Hidromek HMK 200 W wheel excavator?

The Hidromek HMK 200 W has a transport length of 9.66 meters, a transport width of 2.5 meters, and a transport height of 3.57 meters.

What is the travel speed of the Hidromek HMK 200 W wheel excavator?

The Hidromek HMK 200 W has a travel speed of 30 km/h.

What are the undercarriage specifications of the Hidromek HMK 200 W wheel excavator?

The Hidromek HMK 200 W is equipped with 10.00-20 16 PR standard tyres and features 2/4-fold outrigger stabilisers.

What are the excavation performance specifications of the Hidromek HMK 200 W wheel excavator?

The Hidromek HMK 200 W has a dredging depth of 5.79 meters, a maximum horizontal reach of 9.39 meters, and is equipped with a monobloc boom.

What is the tear-out force of the Hidromek HMK 200 W wheel excavator?

The Hidromek HMK 200 W wheel excavator has a tear-out force of 142.19 kN.

What are the bucket specifications of the Hidromek HMK 200 W wheel excavator?

The Hidromek HMK 200 W has a bucket capacity of 0.9 cubic meters and a bucket width of 1.11 meters.

How much is a Hidromek HMK 200 W Wheel excavator (2011u20132020) worth?

The residual value of the Hidromek HMK 200 W depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
