    Caterpillar M318F excavator specs (2017 - 2020)

    Rate this machine now!

    Caterpillar is the manufacturer of the wheel excavator model M 318 F. Find and download detailed specs and data sheets for this ma... Read more

    Caterpillar is the manufacturer of the wheel excavator model M 318 F. Find and download detailed specs and data sheets for this machine here.

    The Caterpillar M 318 F is a 18.5t machine with Caterpillar engine which powers this model with up to 129kW or 172 horse power. This Caterpillar wheel excavator belongs to the medium sized machine segment in the wheel excavators category. The bucket of M 318 F has a capacity of 0,79m³ which is average for this type of machine.

    The Caterpillar M 318 F has been equipped and sold with Aircondition and Blade. It does not include Cabin adjustment, Overload alert and Material Handling Excavator. There are more detailed specifications and machine descriptions available in the original Caterpillar M 318 F specs data sheet.

    This model can be acquired for a list price between €279000 and €355000. Production of the M 318 F continues in 2017. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

    The most commonly viewed Caterpillar models of this type on LECTURA Specs are the M 320 F, M 314 F and M 322 F, and 19 other wheel excavators, which currently range from 13.7t up to 39.5t are also available. Ranked in the LECTURA index at #9, this M 318 F wheel excavator has models that date from 2014 to 2017. We can see currently about 19 models of the M 318 F wheel excavator with an average age of 2 years and average price of €150700. Want more detailed specifications? Download the latest Caterpillar M 318 F specs data sheet on LECTURA Specs today!

    Technical specs - M318F Caterpillar

    Specification

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

    • Weight 17.93 t
    • Standard tyres 10.00-20
    • Bucket capacity 0.91 m³
    • Boom MB
    • Outrigger stabilisers 2 2/4-fold
    • Transport length 8.45 m
    • Transport width 2.55 m
    • Transport height 3.32 m
    • Max. Reach horizontal 8.73 m
    • Dredging depth 5.39 m
    • Tear-out force 114 kN
    • Bucket width 1.2 m
    • Turning radius outside 6.4 m
    • Travel speed 35 km/h
    • Engine manuf. Caterpillar
    • Engine type C7.1 Acert
    • Engine power 126 kW
    • Displacement 7.01 l
    • Revolutions at max torque 1380 rpm
    • Max. torque 783 Nm
    • No. of cylinders 6
    • Cylinder bore x stroke 105x135 mm
    • Emission level Stage IV
    • Bucket capacity min. ###
    • Bucket capacity max. ###
    • Dipper length ###
    • Turning radius inside ###
    • Dimension lxwxh ###
    • Number Of Mono Booms ###
    • Total Number Of Dippers - Mono ###
    • Number Of Articulated Booms ###
    • Total Number Of Dippers - Articulated ###
    • Dipper Length - Standard Articulated ###
    • Telematics Available ###
    • Platform ###
    • Emission Rating ###
    • Engine Manufacturer ###
    • Engine Model ###
    • Rated Speed ###
    • Engine Output - Net ###
    • Transmission Type ###
    • Tyre Size - Standard ###
    • Number Of Tyres - Standard ###
    • Transport Height - Over Mono Boom ###
    • Overall Width ###
    • Wheelbase ###
    • Rear Axle To Slew Centre ###
    • Cab Height ###
    • Ground Clearance ###
    • Machine Width - Maximum ###
    • Overall Width - Stabilisers Down ###
    • Mono Boom Size ###
    • Ground Level Reach - Mono Boom ###
    • Maximum Dig Height - Mono Boom ###
    • Dump Clearance Height - Mono Boom ###
    • Dig Depth - Mono Boom ###
    • Dig Depth - Articulated Boom ###
    • Dozer Blade - Width ###
    • Fuel Tank ###
    • Slew Speed ###
    • Max bucket breakout, Mono Boom ###
    • Dipper Standard, Boost Tearout Artic ###
    • Boom Pressure ###
    • Operating Weight ###

    Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

    Special equipment

    • Diesel particulate filter
    • Blade
    • Cabin adjustment
    • Overload alert
    • Material Handling Excavator
    • Track guidance
    • Aircondition
    • Quick hitch hydr.
    • Quick hitch mech.
