B 55 W 2 Yanmar Excavator Specs & Dimensions - (2010 - 2011)

Yanmar is the manufacturer of the mini excavator model B 55 W 2. Find and download detailed specs and data sheets for this machine…

Yanmar is the manufacturer of the mini excavator model B 55 W 2. Find and download detailed specs and data sheets for this machine here.

Equipped with a powerful Yanmar engine, this B 55 W 2 5.55t machine can provide 39kW or 52 horse power for the mini excavator. The B 55 W 2 is categorised in the biggest machine segment in the mini excavators category. The model's dimensions are 6.19m x 1.92m x 2.86m.

Rubber track, Quick hitch mech. And Quick hitch hydr. Are not provided on this model as of 2011. There are more detailed specifications and machine descriptions available in the original Yanmar B 55 W 2 specs data sheet.

The production stopped in 2011, where this B 55 W 2 was available at a new list price between €78000 and €99000. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

The most commonly viewed Yanmar models of this type on LECTURA Specs are the SV 18 CR, VIO 10-2 A and SV 26 CR, and 24 other mini excavators, which currently range from 0.6t up to 5.5t are also available. Want more detailed specifications? Download the latest Yanmar B 55 W 2 specs data sheet on LECTURA Specs today!

Wheel Excavators Yanmar B 55 W 2

Technical specs - B 55 W 2 Yanmar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
5.55 t
Transport length
6.19 m
Transport width
1.92 m
Transport height
2.86 m
Max. Reach horizontal
4.303 m
Model series
B
Engine manuf.
Yanmar
Engine type
4TNV94L
Engine power
39 kW
Displacement
3.054 l
Revolutions at max torque
2400 rpm

More technical details, like: standard tyres, bucket capacity, bucket capacity min., bucket capacity max., boom, outrigger stabilisers, dredging depth, tear-out force, bucket width, dipper length, turning radius inside, turning radius outside...

More technical details, like: standard tyres, bucket capacity, bucket capacity min., bucket capacity max., boom, outrigger stabilisers, dredging depth, tear-out force, bucket width, dipper length, turning radius inside, turning radius outside, travel speed, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, number of mono booms, total number of dippers - mono, engine manufacturer, engine model, rated speed, engine output - net, number of tyres - standard, tyre size - standard, maximum transport length - mono boom, transport height - over mono boom, overall width, machine width - maximum, wheelbase, cab height, ground clearance, ground level reach - mono boom, maximum dig height - mono boom, dump clearance height - mono boom, dig depth - mono boom, dozer blade - width, fuel tank, slew speed, max bucket breakout, mono boom, number of main pumps, main pumps - maximum flow, boom pressure, operating weight are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Track guidance
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Yanmar B 55 W 2 FAQ

When was the Yanmar B 55 W 2 manufactured?

The Yanmar B 55 W 2 was manufactured from 2010 to 2011.

How much does the Yanmar B 55 W 2 weigh?

The Yanmar B 55 W 2 weighs 5.55 tons.

What are the transport dimensions of the Yanmar B 55 W 2 wheel excavator?

The Yanmar B 55 W 2 has a transport length of 6.19 meters, a transport width of 1.92 meters, and a transport height of 2.86 meters.

What is the maximum horizontal reach of the Yanmar B 55 W 2 wheel excavator?

The Yanmar B 55 W 2 wheel excavator has a maximum horizontal reach of 4.303 meters.

How much is a Yanmar B 55 W 2 Wheel excavator (2010u20132011) worth?

The residual value of the Yanmar B 55 W 2 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
