MH 5 Compact O&K Excavator Specs & Dimensions - (1995 - 2004)

Model rating
7,50 / 10

Manufactured by O&K, this is the MH 5 Compact wheel excavator. Find and download detailed specs and data sheets for this machi…

Manufactured by O&K, this is the MH 5 Compact wheel excavator. Find and download detailed specs and data sheets for this machine here.

The O&K MH 5 Compact is a 18.50t machine with Deutz engine which powers this model with up to 88kW or 118 horse power. This O&K wheel excavator belongs to the medium sized machine segment in the wheel excavators category. The MH 5 Compact’s size is 2.47m x 4.055m x 3.113m. The bucket capacity of MH 5 Compact is 0,5m³, which is above average for this type of machine.

The O&K MH 5 Compact has been equipped and sold with Blade. Track guidance, Aircondition and Overload alert are not provided on this model as of 2004. There are more detailed specifications and machine descriptions available in the original O&K MH 5 Compact specs data sheet. Download a free data sheet in German from LECTURA Specs.

This model can be acquired for a list price between €163000 and €207000. Production of the MH 5 Compact stopped in 2004. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

O&K currently produces other wheel excavators, which range from up to - the most visited on LECTURA Specs are. We can see currently about models of the MH 5 Compact wheel excavator with an average age of 19 years and average price of €18600. Want more detailed specifications? Download the latest O&K MH 5 Compact specs data sheet on LECTURA Specs today!

Wheel Excavators O&K MH 5 Compact

Technical specs - MH 5 Compact O&K

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
18.50 t
Standard tyres
10.00-20
Bucket capacity
0.5 m³
Boom
VA
Transport length
4.055 m
Transport width
2.47 m
Transport height
3.113 m
Max. Reach horizontal
9.1 m
Dredging depth
6.9 m
Tear-out force
84 kN
Bucket width
0.85 m
Model series
MH
Engine manuf.
Deutz
Engine type
BF6M1012
Engine power
88 kW
Displacement
4.788 l
Revolutions at max torque
2200 rpm

More technical details, like: bucket capacity min., bucket capacity max., outrigger stabilisers, dipper length, turning radius inside, turning radius outside, travel speed, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level...

More technical details, like: bucket capacity min., bucket capacity max., outrigger stabilisers, dipper length, turning radius inside, turning radius outside, travel speed, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, number of mono booms, total number of dippers - mono, number of articulated booms, engine manufacturer, engine model, rated speed, engine output - net, transmission type, number of tyres - standard, tyre size - standard, maximum transport length - mono boom, transport height - over mono boom, overall width, machine width - maximum, wheelbase, rear axle to slew centre, tailswing radius, cab height, ground clearance, overall width - stabilisers down, mono boom size, standard dipper length, longest dipper length, ground level reach - mono boom, maximum dig height - mono boom, dump clearance height - mono boom, dig depth - mono boom, ground level reach - articulated boom, maximum dig height - articulated boom, dump clearance height - articulated boom, dig depth - articulated boom, dozer blade - width, fuel tank, slew speed, max bucket breakout, mono boom, number of main pumps, main pumps - maximum flow, boom pressure, operating weight are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Track guidance
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

O&K MH 5 Compact FAQ

When was the O&K MH 5 Compact manufactured?

The O&K MH 5 Compact was manufactured from 1995 to 2004.

How much does the O&K MH 5 Compact weigh?

The O&K MH 5 Compact weighs 18.5 tons.

What are the transport dimensions of the O&K MH 5 Compact wheel excavator?

The O&K MH 5 Compact has a transport length of 4.06 meters, a transport width of 2.47 meters, and a transport height of 3.11 meters.

What are the undercarriage specifications of the O&K MH 5 Compact wheel excavator?

The O&K MH 5 Compact wheel excavator is equipped with standard tyres sized 10.00-20.

What are the excavation performance specifications of the O&K MH 5 Compact wheel excavator?

The O&K MH 5 Compact has an adjustable boom, a maximum horizontal reach of 9.1 meters, and a dredging depth of 6.9 meters.

What is the tear-out force of the O&K MH 5 Compact wheel excavator?

The O&K MH 5 Compact has a tear-out force of 84 kN.

What are the specifications of the primary work tool on the O&K MH 5 Compact wheel excavator?

The primary work tool of the O&K MH 5 Compact has a bucket capacity of 0.5 cubic meters and a bucket width of 0.85 meters.

How much is a O&K MH 5 Compact Wheel excavator (1995u20132004) worth?

The residual value of the O&K MH 5 Compact depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
