MH 5.5 O&K Excavator Specs & Dimensions - (2000 - 2004)

Model rating
4,50 / 10

The MH 5.5 wheel excavator model is manufactured by O&K. Find and download detailed specs and data sheets for this machine her…

The MH 5.5 wheel excavator model is manufactured by O&K. Find and download detailed specs and data sheets for this machine here.

Equipped with a powerful Deutz engine, this MH 5.5 19.9t machine can provide 90kW or 120 horse power for the wheel excavator. The MH 5.5 is categorised in the biggest machine segment in the wheel excavators category. The MH 5.5’s size is 2.75m x 10.31m x 3.14m. The bucket of MH 5.5 has a capacity of 0,5m³ which is average for this type of machine.

Since 2000, this model has included Blade. It has been sold without air Diesel particulate filter, Cabin adjustment and Overload alert as of 2004. There are more detailed specifications and machine descriptions available in the original O&K MH 5.5 specs data sheet. Download a free data sheet in German from LECTURA Specs.

The production stopped in 2004, where this MH 5.5 was available at a new list price between €178000 and €226000. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

At present, other wheel excavators, which range from up to are produced by O&K. Of these, are the most frequently visited on LECTURA Specs. Want more detailed specifications? Download the latest O&K MH 5.5 specs data sheet on LECTURA Specs today!

Wheel Excavators O&K MH 5.5

Technical specs - MH 5.5 O&K

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
19.9 t
Standard tyres
10.00-20
Bucket capacity
0.5 m³
Boom
VA
Outrigger stabilisers
2 2/4-fold
Transport length
10.31 m
Transport width
2.75 m
Transport height
3.14 m
Max. Reach horizontal
12.8 m
Dredging depth
6 m
Model series
MH
Engine manuf.
Deutz
Engine type
BF6M1012E
Engine power
90 kW
Displacement
4.788 l
Revolutions at max torque
2200 rpm

More technical details, like: bucket capacity min., bucket capacity max., tear-out force, bucket width, dipper length, turning radius inside, turning radius outside, travel speed, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke...

More technical details, like: bucket capacity min., bucket capacity max., tear-out force, bucket width, dipper length, turning radius inside, turning radius outside, travel speed, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, number of mono booms, total number of dippers - mono, number of articulated booms, engine manufacturer, engine model, rated speed, engine output - net, transmission type, number of tyres - standard, tyre size - standard, maximum transport length - mono boom, transport height - over mono boom, overall width, machine width - maximum, wheelbase, rear axle to slew centre, tailswing radius, cab height, ground clearance, overall width - stabilisers down, mono boom size, standard dipper length, longest dipper length, ground level reach - mono boom, maximum dig height - mono boom, dump clearance height - mono boom, dig depth - mono boom, ground level reach - articulated boom, maximum dig height - articulated boom, dump clearance height - articulated boom, dig depth - articulated boom, dozer blade - width, fuel tank, slew speed, dipper standard, boost tearout mono, max bucket breakout, mono boom, number of main pumps, main pumps - maximum flow, boom pressure, operating weight are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Track guidance
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

O&K MH 5.5 FAQ

When was the O&K MH 5.5 manufactured?

The O&K MH 5.5 was manufactured from 2000 to 2004.

How much does the O&K MH 5.5 wheel excavator weigh?

The O&K MH 5.5 wheel excavator weighs 19.9 tons.

What are the transport dimensions of the O&K MH 5.5 wheel excavator?

The O&K MH 5.5 has a transport length of 10.31 meters, a transport width of 2.75 meters, and a transport height of 3.14 meters.

What are the undercarriage specifications of the O&K MH 5.5 wheel excavator?

The O&K MH 5.5 wheel excavator is equipped with 10.00-20 standard tyres and has 2 outrigger stabilisers.

What are the excavation performance specifications of the O&K MH 5.5 wheel excavator?

The O&K MH 5.5 wheel excavator has a dredging depth of 6 meters, a maximum horizontal reach of 12.8 meters, and features an adjustable boom.

What is the bucket capacity of the O&K MH 5.5 wheel excavator?

The O&K MH 5.5 wheel excavator has a bucket capacity of 0.5 cubic meters.

How much is a O&K MH 5.5 Wheel excavator (2000u20132004) worth?

The residual value of the O&K MH 5.5 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
