MH Plus New Holland Excavator Specs & Dimensions - (2008 - 2012)

The MH Plus wheel excavator model is manufactured by New Holland. Find and download detailed specs and data sheets for this machin…

The MH Plus wheel excavator model is manufactured by New Holland. Find and download detailed specs and data sheets for this machine here.

This wheel excavator is built to provide up to 105kW or 140 horse power, delivered from its powerful CNH engine to the 17.5t MH Plus machine. This New Holland wheel excavator belongs to the medium sized machine segment in the wheel excavators category. The model's dimensions are 8.43m x 3.9m x 3.01m. The bucket of MH Plus has a capacity of 0,81m³ which is average for this type of machine.

Blade, Quick hitch mech. And Quick hitch hydr. Are not provided on this model as of 2012. There are more detailed specifications and machine descriptions available in the original New Holland MH Plus specs data sheet.

This model can be acquired for a list price between €146000 and €186000. Production of the MH Plus stopped in 2012. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

At present, 5 other wheel excavators, which range from 15.4t up to 21.5t are produced by New Holland. Of these, WE 170 B pro, WE 150 B pro and also WE 190 B pro are the most frequently visited on LECTURA Specs. Currently, 5 models of the MH Plus wheel excavator exist, at an average sale value of €31000 at 9 years of age. Want more detailed specifications? Download the latest New Holland MH Plus specs data sheet on LECTURA Specs today!

Wheel Excavators New Holland MH Plus

Technical specs - MH Plus New Holland

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
17.5 t
Standard tyres
10.00-20
Bucket capacity
0.81 m³
Boom
VA
Transport length
8.43 m
Transport width
3.9 m
Transport height
3.01 m
Max. Reach horizontal
9.635 m
Dredging depth
5.455 m
Tear-out force
70.7 kN
Model series
MH
Engine manuf.
CNH
Engine type
667TA-BEC
Engine power
105 kW
Displacement
6.7 l
Revolutions at max torque
1200 rpm

More technical details, like: bucket capacity min., bucket capacity max., outrigger stabilisers, bucket width, dipper length, turning radius inside, turning radius outside, travel speed, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke...

More technical details, like: bucket capacity min., bucket capacity max., outrigger stabilisers, bucket width, dipper length, turning radius inside, turning radius outside, travel speed, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, number of mono booms, total number of dippers - mono, number of articulated booms, engine manufacturer, engine model, rated speed, engine output - net, number of tyres - standard, tyre size - standard, maximum transport length - mono boom, transport height - over mono boom, overall width, machine width - maximum, wheelbase, rear axle to slew centre, tailswing radius, cab height, ground clearance, overall width - stabilisers down, mono boom size, standard dipper length, longest dipper length, ground level reach - mono boom, maximum dig height - mono boom, dump clearance height - mono boom, dig depth - mono boom, ground level reach - articulated boom, maximum dig height - articulated boom, dump clearance height - articulated boom, dig depth - articulated boom, dozer blade - width, fuel tank, slew speed, dipper standard, boost tearout mono, max bucket breakout, mono boom, number of main pumps, main pumps - maximum flow, boom pressure, operating weight are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Track guidance
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

New Holland MH Plus FAQ

When was the New Holland MH Plus manufactured?

The New Holland MH Plus was manufactured from 2008 to 2012.

How much does the New Holland MH Plus wheel excavator weigh?

The New Holland MH Plus wheel excavator weighs 17.5 tons.

What are the transport dimensions of the New Holland MH Plus wheel excavator?

The New Holland MH Plus has a transport length of 8.43 meters, a transport width of 3.9 meters, and a transport height of 3.01 meters.

What are the undercarriage specifications of the New Holland MH Plus wheel excavator?

The New Holland MH Plus wheel excavator is equipped with standard tyres sized 10.00-20.

What are the excavation performance specifications of the New Holland MH Plus wheel excavator?

The New Holland MH Plus wheel excavator has a dredging depth of 5.455 meters, a maximum horizontal reach of 9.635 meters, and features an adjustable boom.

What is the tear-out force of the New Holland MH Plus wheel excavator?

The New Holland MH Plus wheel excavator has a tear-out force of 70.7 kN.

What is the bucket capacity of the New Holland MH Plus wheel excavator?

The New Holland MH Plus wheel excavator has a bucket capacity of 0.81 cubic meters.

How much is a New Holland MH Plus Wheel excavator (2008u20132012) worth?

The residual value of the New Holland MH Plus depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
