A 916 Compact Litronic G6.0 Liebherr Excavator Specs & Dimensions - (2020 - 2026)

Weight: 16.3t – Standard tyres: 10.00-20 – Bucket capacity: 0.5m³ – Boom: VA – Outrigger stabilisers: 22/4-fold – Transport length…

Weight: 16.3t – Standard tyres: 10.00-20 – Bucket capacity: 0.5m³ – Boom: VA – Outrigger stabilisers: 22/4-fold – Transport length: 8m

Check out detailed dimensions, specifications, information and technical data for Liebherr A 916 Compact Litronic G6.0 excavator manufactured between 2020 - 2026. Get more in-depth insight with Liebherr A 916 Compact Litronic G6.0 digger specifications. See information, like: Weight: 16.3t – Standard tyres: 10.00-20 – Bucket capacity: 0.5m³ – Boom: VA – Outrigger stabilisers: 22/4-fold – Transport length: 8m and more.

Wheel Excavators Liebherr A 916 Compact Litronic G6.0
Wheel Excavators Liebherr A 916 Compact Litronic G6.0
Wheel Excavators Liebherr A 916 Compact Litronic G6.0
Wheel Excavators Liebherr A 916 Compact Litronic G6.0
Wheel Excavators Liebherr A 916 Compact Litronic G6.0
Wheel Excavators Liebherr A 916 Compact Litronic G6.0
Wheel Excavators Liebherr A 916 Compact Litronic G6.0
Wheel Excavators Liebherr A 916 Compact Litronic G6.0

Visit Liebherr live at

Technical specs - A 916 Compact Litronic G6.0 Liebherr

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
16.3 t
Standard tyres
10.00-20
Bucket capacity
0.5 m³
Boom
VA
Outrigger stabilisers
2 2/4-fold
Transport length
8 m
Transport width
2.55 m
Transport height
3.17 m
Max. Reach horizontal
8.55 m
Dredging depth
5.35 m
Tear-out force
85.1 kN
Bucket width
0.85 m
Dipper length
2.45 m
Travel speed
37 km/h
Engine manuf.
FPT
Engine type
D924
Engine power
110 kW
Displacement
4.5 l
Revolutions at max torque
1800 rpm
No. of cylinders
4
Cylinder bore x stroke
104x132 mm
Emission level
V

More technical details, like: bucket capacity min., bucket capacity max., turning radius inside, turning radius outside, model series, dimension lxwxh, max. torque are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Blade
Yes
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
No
Track guidance
No
Aircondition
Yes
Quick hitch hydr.
Yes
Quick hitch mech.
Yes

Download datasheets (PDF)

Liebherr A 916 Compact Litronic G6.0 FAQ

When was the Liebherr A 916 Compact Litronic manufactured?

The Liebherr A 916 Compact Litronic was first produced in 2020.

How much does the Liebherr A 916 Compact Litronic weigh?

The Liebherr A 916 Compact Litronic weighs 16.3 tons.

What are the transport dimensions of the Liebherr A 916 Compact Litronic wheel excavator?

The Liebherr A 916 Compact Litronic has a transport length of 8 meters, a transport width of 2.55 meters, and a transport height of 3.17 meters.

What is the travel speed of the Liebherr A 916 Compact Litronic wheel excavator?

The Liebherr A 916 Compact Litronic has a travel speed of 30 km/h.

What are the undercarriage specifications of the Liebherr A 916 Compact Litronic wheel excavator?

The Liebherr A 916 Compact Litronic is equipped with 10.00-20 standard tyres and has 2 outrigger stabilisers.

What are the excavation performance specifications of the Liebherr A 916 Compact Litronic wheel excavator?

The Liebherr A 916 Compact Litronic has a dredging depth of 5.55 meters, a maximum horizontal reach of 8.75 meters, features an adjustable boom, and has a dipper length of 2.65 meters.

What is the tear-out force of the Liebherr A 916 Compact Litronic wheel excavator?

The Liebherr A 916 Compact Litronic wheel excavator has a tear-out force of 85.1 kN.

What are the specifications of the bucket on the Liebherr A 916 Compact Litronic wheel excavator?

The bucket of the Liebherr A 916 Compact Litronic has a capacity of 0.5 cubic meters and a width of 0.85 meters.

How much is a Liebherr A 916 Compact Litronic Wheel excavator (2020u20132025) worth?

The residual value of the Liebherr A 916 Compact Litronic depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Liebherr A 916 Compact Litronic G6.0 overview

Liebherr A 916 Compact Litronic features overview

Fast and Effective Work on the Construction Site

The A 916 Compact Litronic wheeled excavator is a real power pack that ensures versatility and productivity. A high performance engine guarantees fast acceleration, high speed and maximum handling capacity – optimum features for any construction site.


Engine

Smooth Operation

The use of visco-elastic mounts, good noise insulation and modern, smooth Liebherr diesel engines minimise noise emissions and vibrations.


Operator's cab

Productive Working Environment

The spacious Liebherr cab offers plenty of room for long working days and ensures the best platform for all-round visibility thanks to large window areas and narrow bars. All gear levers and control panels are located within reach and fit the ergonomic concept of the operator’s cab perfectly. The temperature, fan setting and the standard automatic air-conditioning’s head, chest and foot level air vents can be adjusted with ease using touchscreen control.


Radio with Hands-free Device

The optional Liebherr radio is MP3-compatible, has a USB connection and can be used as interface for the integral hands-free kit. If the machine operator connects his smartphone to the radio using Bluetooth, the touchscreen can be used to control phone calls. This means that all media, including the radio, MP3 or phone calls, are controlled using a central unit which provides greater clarity, simplicity and comfort.


Safety

Safety

In addition to the performance and economy of a wheeled excavator, the safety of the machine is the safety of the operator and the machine. A wide range of equipment such as pipe fracture safety devices on lifting and stick cylinders, load holding valves on outriggers, optional lift limitation in height, overload warning device, roll-over protection system (ROPS), and the emergency exit through the rear window deliver maximum safety for every job.


Booms and sticks

Lift Capacities of Liebherr Quick Coupler SWA 33

The lift capacities on the load lift hook of the Liebherr quick coupler SWA 33 without attachment are stated in metric tons (t) and are valid on a firm, level supporting surface with blocked oscillating axle. These capacities can be slewed through 360° with the undercarriage in the transverse position. Capacities in the longitudinal position of the undercarriage (a = 15°) are specified over the steering axle with the stabilizers raised or over the rigid axle with the stabilizers down. Indicated loads are based on the ISO 10567 standard and do not exceed 75% of tipping or 87% of hydraulic capacity, or are limited by the permissible load of the load lift hook on the quick coupler (max. 5 t). Without the quick coupler, lift capacities will increase by up to 110 kg. In accordance with the harmonised European Standard EN 474-5, hydraulic excavators used for lifting operations must be equipped with pipe fracture safety valves, an overload warning device, a load lift hook, and a lift capacity chart.
