WX 210 S-3 Case Excavator Specs & Dimensions - (2008 - 2014)

case is the manufacturer of the wheel excavator model WX 210 S-3. Find and download detailed specs and data sheets for this machin…

case is the manufacturer of the wheel excavator model WX 210 S-3. Find and download detailed specs and data sheets for this machine here.

Equipped with a powerful case engine, this WX 210 S-3 19.6t machine can provide 129kW or 172 horse power for the wheel excavator. The case WX 210 S-3 can be grouped in the biggest machine segment in the wheel excavators category. The model's dimensions are 9.68m x 2.53m x 2.42m. The bucket capacity of WX 210 S-3 is 1,09m³, which is above average for this type of machine.

The WX 210 S-3 is manufactured and distributed with Blade. It has been sold without air Diesel particulate filter, Quick hitch mech. And Cabin adjustment as of 2014. There are more detailed specifications and machine descriptions available in the original case WX 210 S-3 specs data sheet. Download a free data sheet in English, French, Italian, German and Spanish from LECTURA Specs.

The production stopped in 2014, where this WX 210 S-3 was available at a new list price between €229000 and €292000. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

At present, 4 other wheel excavators, which range from 15.4t up to 20.8t are produced by case. Of these, WX 148, WX 168 and also WX 188 are the most frequently visited on LECTURA Specs. Want more detailed specifications? Download the latest case WX 210 S-3 specs data sheet on LECTURA Specs today!

Wheel Excavators Case WX 210 S-3

Technical specs - WX 210 S-3 Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
19.6 t
Standard tyres
18-22.5XF
Bucket capacity
1.09 m³
Boom
MB
Outrigger stabilisers
2 2/4-fold
Transport length
9.68 m
Transport width
2.53 m
Transport height
2.42 m
Max. Reach horizontal
9.5 m
Dredging depth
5.6 m
Tear-out force
121.4 kN
Bucket width
1.2 m
Model series
S
Engine manuf.
Case
Engine type
667TA-MEE
Engine power
129 kW
Displacement
6.7 l
Revolutions at max torque
2000 rpm

More technical details, like: bucket capacity min., bucket capacity max., dipper length, turning radius inside, turning radius outside, travel speed, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Track guidance
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Case WX 210 S-3 FAQ

When was the Case WX 210 S-3 manufactured?

The Case WX 210 S-3 was manufactured from 2008 to 2014.

How much does the Case WX 210 S-3 wheel excavator weigh?

The Case WX 210 S-3 wheel excavator weighs 19.6 tons.

What are the transport dimensions of the Case WX 210 S-3 wheel excavator?

The Case WX 210 S-3 has a transport length of 9.68 meters, a transport width of 2.53 meters, and a transport height of 2.42 meters.

What are the undercarriage specifications of the Case WX 210 S-3 wheel excavator?

The Case WX 210 S-3 is equipped with 18-22.5XF standard tyres and has 2 outrigger stabilisers.

What are the excavation performance specifications of the Case WX 210 S-3?

The Case WX 210 S-3 has a dredging depth of 5.6 meters, a maximum horizontal reach of 9.5 meters, and is equipped with a Monobloc boom.

What is the tear-out force of the Case WX 210 S-3 wheel excavator?

The Case WX 210 S-3 wheel excavator has a tear-out force of 121.4 kN.

What are the bucket specifications of the Case WX 210 S-3 wheel excavator?

The Case WX 210 S-3 wheel excavator has a bucket capacity of 1.09 cubic meters and a bucket width of 1.2 meters.

How much is a Case WX 210 S-3 Wheel excavator (2008u20132014) worth?

The residual value of the Case WX 210 S-3 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
