888 BP 4A Case Poclain Excavator Specs & Dimensions - (1993 - 1995)

Case Poclain is the manufacturer of the wheel excavator model 888 BP 4A. Find and download detailed specs and data sheets for this…

Case Poclain is the manufacturer of the wheel excavator model 888 BP 4A. Find and download detailed specs and data sheets for this machine here.

Equipped with a powerful case engine, this 888 BP 4A 16t machine can provide 87.5kW or 117 horse power for the wheel excavator. This Case Poclain wheel excavator belongs to the medium sized machine segment in the wheel excavators category. The model's dimensions are 8.7m x 2.48m x 3.3m. The bucket capacity of 888 BP 4A is 1m³, which is above average for this type of machine.

Cabin adjustment, Aircondition and Quick hitch hydr. Are not provided on this model as of 1995. There are more detailed specifications and machine descriptions available in the original Case Poclain 888 BP 4A specs data sheet. Available in German, LECTURA Specs offers a free download of highly detailed specifications and machine descriptions of this model.

This model can be acquired for a list price between €154000 and €197000. Production of the 888 BP 4A stopped in 1995. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

Case Poclain currently produces other wheel excavators, which range from up to - the most visited on LECTURA Specs are. Want more detailed specifications? Download the latest Case Poclain 888 BP 4A specs data sheet on LECTURA Specs today!

Wheel Excavators Case Poclain 888 BP 4A

Technical specs - 888 BP 4A Case Poclain

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
16 t
Standard tyres
10.00-20
Bucket capacity
1 m³
Transport length
8.7 m
Transport width
2.48 m
Transport height
3.3 m
Model series
BP
Engine manuf.
Case
Engine type
6T 590
Engine power
87.5 kW

More technical details, like: bucket capacity min., bucket capacity max., boom, outrigger stabilisers, max. reach horizontal, dredging depth, tear-out force, bucket width, dipper length, turning radius inside, turning radius outside, travel speed...

More technical details, like: bucket capacity min., bucket capacity max., boom, outrigger stabilisers, max. reach horizontal, dredging depth, tear-out force, bucket width, dipper length, turning radius inside, turning radius outside, travel speed, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Track guidance
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Case Poclain 888 BP 4A FAQ

When was the Case Poclain 888 BP 4A manufactured?

The Case Poclain 888 BP 4A was manufactured from 1993 to 1995.

How much does the Case Poclain 888 BP 4A weigh?

The Case Poclain 888 BP 4A weighs 16 tons.

What are the transport dimensions of the Case Poclain 888 BP 4A wheel excavator?

The Case Poclain 888 BP 4A has a transport length of 8.7 meters, a transport width of 2.48 meters, and a transport height of 3.3 meters.

What are the undercarriage specifications of the Case Poclain 888 BP 4A?

The Case Poclain 888 BP 4A is equipped with standard tyres sized 10.00-20.

What is the bucket capacity of the Case Poclain 888 BP 4A wheel excavator?

The bucket capacity of the Case Poclain 888 BP 4A wheel excavator is 1 cubic meter.

How much is a Case Poclain 888 BP 4A Wheel excavator (1993u20131995) worth?

The residual value of the Case Poclain 888 BP 4A depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
