B110W Yanmar Excavator Specs & Dimensions - (2022 - 2026)

Weight: 11t – Standard tyres: 9.00-20, 14 PR Zwillingsbereifung – Bucket capacity min.: 1.49m³ – Bucket capacity max.: 4.77m³ – Tr…

Weight: 11t – Standard tyres: 9.00-20, 14 PR Zwillingsbereifung – Bucket capacity min.: 1.49m³ – Bucket capacity max.: 4.77m³ – Transport length: 7.9m – Transport width: 2.5m

Check out detailed dimensions, specifications, information and technical data for Yanmar B110W excavator manufactured between 2022 - 2026. Get more in-depth insight with Yanmar B110W digger specifications. See information, like: Weight: 11t – Standard tyres: 9.00-20, 14 PR Zwillingsbereifung – Bucket capacity min.: 1.49m³ – Bucket capacity max.: 4.77m³ – Transport length: 7.9m – Transport width: 2.5m and more.

Wheel Excavators Yanmar B110W
Wheel Excavators Yanmar B110W
Wheel Excavators Yanmar B110W
Wheel Excavators Yanmar B110W
Wheel Excavators Yanmar B110W
Wheel Excavators Yanmar B110W
Wheel Excavators Yanmar B110W
Wheel Excavators Yanmar B110W
Wheel Excavators Yanmar B110W
Wheel Excavators Yanmar B110W

Technical specs - B110W Yanmar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
11 t
Standard tyres
9.00-20, 14 PR Zwillingsbereifung
Bucket capacity min.
1.49 m³
Bucket capacity max.
4.77 m³
Transport length
7.9 m
Transport width
2.5 m
Transport height
2.99 m
Max. Reach horizontal
8.09 m
Dredging depth
4.44 m
Tear-out force
58.5 kN
Travel speed
36 km/h
Model series
B
Engine manuf.
Deutz
Engine type
TCD3.6 L4
Engine power
85 kW
Displacement
3.6 l
Revolutions at max torque
2000 rpm
Max. torque
460/1600 Nm
No. of cylinders
4
Emission level
EU V / Tier-4 f

More technical details, like: bucket capacity, boom, outrigger stabilisers, bucket width, dipper length, turning radius inside, turning radius outside, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Track guidance
No
Aircondition
Yes
Quick hitch hydr.
Yes
Quick hitch mech.
No

Download datasheets (PDF)

Yanmar B110W FAQ

When was the Yanmar B110W manufactured?

The Yanmar B110W was first produced in 2024.

How much does the Yanmar B110W wheel excavator weigh?

The Yanmar B110W wheel excavator weighs 11 tons.

What are the transport dimensions of the Yanmar B110W wheel excavator?

The Yanmar B110W has a transport length of 7.9 meters, a transport width of 2.5 meters, and a transport height of 2.99 meters.

What is the travel speed of the Yanmar B110W wheel excavator?

The Yanmar B110W wheel excavator has a travel speed of 36 km/h.

What are the undercarriage specifications of the Yanmar B110W wheel excavator?

The Yanmar B110W wheel excavator is equipped with standard tyres sized 9.00-20, 14 PR Zwillingsbereifung.

What are the excavation performance specifications of the Yanmar B110W wheel excavator?

The Yanmar B110W wheel excavator has a dredging depth of 4.44 meters and a maximum horizontal reach of 8.09 meters.

What is the tear-out force of the Yanmar B110W wheel excavator?

The Yanmar B110W wheel excavator has a tear-out force of 58.5 kN.

What are the bucket capacity specifications of the Yanmar B110W wheel excavator?

The Yanmar B110W wheel excavator has a bucket capacity ranging from 1.49 to 4.77 cubic meters.

How much is a Yanmar B110W Wheel excavator (2024u20132025) worth?

The residual value of the Yanmar B110W depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
