EW180D Volvo Excavator Specs & Dimensions - (2012 - 2016)

Volvo is the manufacturer of the wheel excavator model EW 180 D. Find and download detailed specs and data sheets for this machine…

Volvo is the manufacturer of the wheel excavator model EW 180 D. Find and download detailed specs and data sheets for this machine here.

This wheel excavator is built to provide up to 129kW or 172 horse power, delivered from its powerful Volvo engine to the 19.1t EW 180 D machine. The Volvo EW 180 D can be grouped in the biggest machine segment in the wheel excavators category. The EW 180 D’s size is 2.54m x 8.8m x 3.12m. The bucket of EW 180 D has a capacity of 0,87m³ which is average for this type of machine.

Since 2012, this model has included Overload alert and Blade. It does not include Diesel particulate filter, Cabin adjustment and Track guidance. There are more detailed specifications and machine descriptions available in the original Volvo EW 180 D specs data sheet. Specification sheet is available for a free download in French, German, Italian, Spanish and English - providing the machine descriptions and more detailed specs about this particular model.

This model can be acquired for a list price between €274000 and €348000. Production of the EW 180 D stopped in 2016. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

Volvo currently produces 8 other wheel excavators, which range from 7.2t up to 22.2t - the most visited on LECTURA Specs are EW 210 D, EW 140 D, EW 60 E. Want more detailed specifications? Download the latest Volvo EW 180 D specs data sheet on LECTURA Specs today!

Wheel Excavators Volvo EW180D
Wheel Excavators Volvo EW180D
Wheel Excavators Volvo EW180D
Wheel Excavators Volvo EW180D
Wheel Excavators Volvo EW180D
Wheel Excavators Volvo EW180D
Wheel Excavators Volvo EW180D
Wheel Excavators Volvo EW180D

Visit Volvo live at

Technical specs - EW180D Volvo

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
19.1 t
Standard tyres
10.00x20
Bucket capacity
0.87 m³
Transport length
8.8 m
Transport width
2.54 m
Transport height
3.12 m
Max. Reach horizontal
9.84 m
Dredging depth
6.3 m
Model series
EW
Engine manuf.
Volvo
Engine type
D 6 H
Engine power
129 kW
Displacement
5.7 l
Revolutions at max torque
1350 rpm

More technical details, like: bucket capacity min., bucket capacity max., boom, outrigger stabilisers, tear-out force, bucket width, dipper length, turning radius inside, turning radius outside, travel speed, dimension lxwxh, max. torque...

More technical details, like: bucket capacity min., bucket capacity max., boom, outrigger stabilisers, tear-out force, bucket width, dipper length, turning radius inside, turning radius outside, travel speed, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, number of mono booms, total number of dippers - mono, number of articulated booms, emission rating, engine manufacturer, engine model, rated speed, engine output - net, transmission type, number of tyres - standard, tyre size - standard, maximum transport length - mono boom, transport height - over mono boom, overall width, machine width - maximum, wheelbase, rear axle to slew centre, tailswing radius, cab height, ground clearance, overall width - stabilisers down, mono boom size, standard dipper length, longest dipper length, ground level reach - mono boom, maximum dig height - mono boom, dump clearance height - mono boom, dig depth - mono boom, ground level reach - articulated boom, maximum dig height - articulated boom, dump clearance height - articulated boom, dig depth - articulated boom, dozer blade - width, fuel tank, slew speed, max bucket breakout, mono boom, max bucket breakout, artic boom, number of main pumps, main pumps - maximum flow, boom pressure, operating weight are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Blade
Yes
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
No
Track guidance
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Volvo EW180D FAQ

When was the Volvo EW180D manufactured?

The Volvo EW180D was manufactured from 2012 to 2016.

How much does the Volvo EW180D wheel excavator weigh?

The Volvo EW180D wheel excavator weighs 19.1 tons.

What are the transport dimensions of the Volvo EW180D wheel excavator?

The Volvo EW180D has a transport length of 8.8 meters, a transport width of 2.54 meters, and a transport height of 3.12 meters.

What is the size of the standard tyres on the Volvo EW180D wheel excavator?

The Volvo EW180D wheel excavator has standard tyres sized 10.00x20.

What are the excavation performance specifications of the Volvo EW180D?

The Volvo EW180D has a dredging depth of 6.3 meters and a maximum horizontal reach of 9.84 meters.

What is the bucket capacity of the Volvo EW180D wheel excavator?

The bucket capacity of the Volvo EW180D wheel excavator is 0.87 cubic meters.

How much is a Volvo EW180D Wheel excavator (2012u20132016) worth?

The residual value of the Volvo EW180D depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
