E7160H SDLG Excavator Specs & Dimensions - (2026 - 2026)

Weight: 16.4t – Bucket capacity: 0.6m³ – Transport length: 7.77m – Transport width: 2.52m – Transport height: 3.15m – Max. Reach h…

Weight: 16.4t – Bucket capacity: 0.6m³ – Transport length: 7.77m – Transport width: 2.52m – Transport height: 3.15m – Max. Reach horizontal: 7.985m

Check out detailed dimensions, specifications, information and technical data for SDLG E7160H excavator manufactured between 2026 - 2026. Get more in-depth insight with SDLG E7160H digger specifications. See information, like: Weight: 16.4t – Bucket capacity: 0.6m³ – Transport length: 7.77m – Transport width: 2.52m – Transport height: 3.15m – Max. Reach horizontal: 7.985m and more.

Technical specs - E7160H SDLG

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
16.4 t
Bucket capacity
0.6 m³
Transport length
7.77 m
Transport width
2.52 m
Transport height
3.15 m
Max. Reach horizontal
7.985 m
Dredging depth
4.995 m
Tear-out force
75.7 kN
Travel speed
37.5 km/h
Model series
H
Engine manuf.
Deutz
Engine type
BF6M2012-17T2
Engine power
123 kW
Displacement
6.06 l
Revolutions at max torque
1350 rpm
Max. torque
695 Nm
No. of cylinders
6
Emission level
Stage II

More technical details, like: standard tyres, bucket capacity min., bucket capacity max., boom, outrigger stabilisers, bucket width, dipper length, turning radius inside, turning radius outside, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Track guidance
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No
