MH 4.5 O&K Excavator Specs & Dimensions - (2000 - 2005)

Model rating
5,00 / 10

The MH 4.5 wheel excavator model is manufactured by O&K. Find and download detailed specs and data sheets for this machine her…

The MH 4.5 wheel excavator model is manufactured by O&K. Find and download detailed specs and data sheets for this machine here.

This wheel excavator is built to provide up to 61kW or 81 horse power, delivered from its powerful Deutz engine to the 13.5t MH 4.5 machine. This O&K wheel excavator belongs to the smallest machine segment in the wheel excavators category. The model's dimensions are 3.98m x 2.5m x 3.1m. The bucket capacity of MH 4.5 is 0,5m³, which is above average for this type of machine.

The O&K MH 4.5 has been equipped and sold with Blade. It has been sold without air Quick hitch mech., Aircondition and Cabin adjustment as of 2005. There are more detailed specifications and machine descriptions available in the original O&K MH 4.5 specs data sheet. You can download it for free in German on LECTURA Specs.

This model can be acquired for a list price between €140000 and €179000. Production of the MH 4.5 stopped in 2005. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

The most commonly viewed O&K models of this type on LECTURA Specs are the, and other wheel excavators, which currently range from up to are also available. Want more detailed specifications? Download the latest O&K MH 4.5 specs data sheet on LECTURA Specs today!

Wheel Excavators O&K MH 4.5

Technical specs - MH 4.5 O&K

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
13.5 t
Standard tyres
10.00-20
Bucket capacity
0.5 m³
Boom
VA
Transport length
3.98 m
Transport width
2.5 m
Transport height
3.1 m
Max. Reach horizontal
9.4 m
Dredging depth
5.7 m
Tear-out force
53 kN
Bucket width
0.85 m
Model series
MH
Engine manuf.
Deutz
Engine type
BF4M1012
Engine power
61 kW
Displacement
3.2 l
Revolutions at max torque
2300 rpm

More technical details, like: bucket capacity min., bucket capacity max., outrigger stabilisers, dipper length, turning radius inside, turning radius outside, travel speed, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level...

More technical details, like: bucket capacity min., bucket capacity max., outrigger stabilisers, dipper length, turning radius inside, turning radius outside, travel speed, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, number of mono booms, total number of dippers - mono, number of articulated booms, engine manufacturer, engine model, rated speed, engine output - net, transmission type, number of tyres - standard, tyre size - standard, maximum transport length - mono boom, transport height - over mono boom, overall width, machine width - maximum, wheelbase, rear axle to slew centre, tailswing radius, cab height, ground clearance, overall width - stabilisers down, mono boom size, standard dipper length, longest dipper length, ground level reach - mono boom, maximum dig height - mono boom, dump clearance height - mono boom, dig depth - mono boom, ground level reach - articulated boom, maximum dig height - articulated boom, dump clearance height - articulated boom, dig depth - articulated boom, dozer blade - width, fuel tank, slew speed, dipper standard, boost tearout mono, max bucket breakout, mono boom, number of main pumps, main pumps - maximum flow, boom pressure, operating weight are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Track guidance
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

O&K MH 4.5 FAQ

When was the O&K MH 4.5 manufactured?

The O&K MH 4.5 was manufactured from 2000 to 2005.

How much does the O&K MH 4.5 wheel excavator weigh?

The O&K MH 4.5 wheel excavator weighs 13.5 tons.

What are the transport dimensions of the O&K MH 4.5 wheel excavator?

The O&K MH 4.5 has transport dimensions of 3.98 meters in length, 2.5 meters in width, and 3.1 meters in height.

What are the undercarriage specifications of the O&K MH 4.5 wheel excavator?

The O&K MH 4.5 wheel excavator is equipped with standard tyres sized 10.00-20.

What are the excavation performance specifications of the O&K MH 4.5 wheel excavator?

The O&K MH 4.5 wheel excavator has a dredging depth of 5.7 meters, a maximum horizontal reach of 9.4 meters, and features an adjustable boom.

What is the tear-out force of the O&K MH 4.5 wheel excavator?

The O&K MH 4.5 wheel excavator has a tear-out force of 53 kN.

What are the specifications of the primary work tool on the O&K MH 4.5 wheel excavator?

The primary work tool of the O&K MH 4.5 wheel excavator has a bucket capacity of 0.5 cubic meters and a bucket width of 0.85 meters.

How much is a O&K MH 4.5 Wheel excavator (2000u20132005) worth?

The residual value of the O&K MH 4.5 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
