MH 2.5 O&K Excavator Specs & Dimensions - (1987 - 2005)

Model rating
9,00 / 10

O&K is the manufacturer of the wheel excavator model MH 2.5. Find and download detailed specs and data sheets for this machine…

O&K is the manufacturer of the wheel excavator model MH 2.5. Find and download detailed specs and data sheets for this machine here.

The O&K MH 2.5 is a 4.50t machine with Deutz engine which powers this model with up to 31.0kW or 41 horse power. This O&K wheel excavator belongs to the smallest machine segment in the wheel excavators category. The model's dimensions are 6.64m x 2.2m x 2.95m. The bucket of MH 2.5 has a capacity of 0,07m³ which is average for this type of machine.

Since 1987, this model has included Blade. It has been sold without air Overload alert, Track guidance and Diesel particulate filter as of 2005. There are more detailed specifications and machine descriptions available in the original O&K MH 2.5 specs data sheet. Available in German, LECTURA Specs offers a free download of highly detailed specifications and machine descriptions of this model.

The production stopped in 2005, where this MH 2.5 was available at a new list price between €55000 and €71000. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

At present, other wheel excavators, which range from up to are produced by O&K. Of these, are the most frequently visited on LECTURA Specs. Want more detailed specifications? Download the latest O&K MH 2.5 specs data sheet on LECTURA Specs today!

Wheel Excavators O&K MH 2.5

Technical specs - MH 2.5 O&K

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
4.5 t
Standard tyres
15.5/55R18
Bucket capacity
0.07 m³
Boom
VA
Transport length
6.64 m
Transport width
2.2 m
Transport height
2.95 m
Max. Reach horizontal
5.6 m
Dredging depth
3.625 m
Tear-out force
44 kN
Bucket width
0.8 m
Model series
MH
Engine manuf.
Deutz
Engine type
F3L912
Engine power
31 kW

More technical details, like: bucket capacity min., bucket capacity max., outrigger stabilisers, dipper length, turning radius inside, turning radius outside, travel speed, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders...

More technical details, like: bucket capacity min., bucket capacity max., outrigger stabilisers, dipper length, turning radius inside, turning radius outside, travel speed, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level, number of mono booms, total number of dippers - mono, number of articulated booms, engine manufacturer, rated speed, engine output - net, transmission type, number of tyres - standard, tyre size - standard, maximum transport length - mono boom, transport height - over mono boom, overall width, machine width - maximum, wheelbase, rear axle to slew centre, cab height, ground clearance, standard dipper length, longest dipper length, ground level reach - mono boom, maximum dig height - mono boom, dump clearance height - mono boom, dig depth - mono boom, ground level reach - articulated boom, maximum dig height - articulated boom, dump clearance height - articulated boom, dig depth - articulated boom, dozer blade - width, fuel tank, slew speed, max bucket breakout, mono boom, main pumps - maximum flow, boom pressure, operating weight are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Track guidance
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

O&K MH 2.5 FAQ

When was the O&K MH 2.5 manufactured?

The O&K MH 2.5 was manufactured from 1987 to 2005.

How much does the O&K MH 2.5 weigh?

The O&K MH 2.5 weighs 4.5 tons.

What are the transport dimensions of the O&K MH 2.5 wheel excavator?

The O&K MH 2.5 has a transport length of 6.64 meters, a transport width of 2.2 meters, and a transport height of 2.95 meters.

What are the undercarriage specifications of the O&K MH 2.5 wheel excavator?

The O&K MH 2.5 wheel excavator is equipped with standard tyres sized 15.5/55R18.

What are the excavation performance specifications of the O&K MH 2.5 wheel excavator?

The O&K MH 2.5 wheel excavator has a dredging depth of 3.625 meters, a maximum horizontal reach of 5.6 meters, and features an adjustable boom.

What is the tear-out force of the O&K MH 2.5 wheel excavator, given that no power rating data is available?

The O&K MH 2.5 wheel excavator has a tear-out force of 44 kN; no power rating data is provided in the source.

What are the specifications of the bucket on the O&K MH 2.5 wheel excavator?

The bucket of the O&K MH 2.5 has a capacity of 0.07 cubic meters and a width of 0.8 meters.

How much is a O&K MH 2.5 Wheel excavator (1987u20132005) worth?

The residual value of the O&K MH 2.5 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
