MH 3.6 WT New Holland Excavator Specs & Dimensions - (2008 - 2014)

New Holland is the manufacturer of the wheel excavator model MH 3.6 WT. Find and download detailed specs and data sheets for this …

New Holland is the manufacturer of the wheel excavator model MH 3.6 WT. Find and download detailed specs and data sheets for this machine here.

The New Holland MH 3.6 WT is a 12t machine with CNH engine which powers this model with up to 84kW or 112 horse power. This New Holland wheel excavator belongs to the smallest machine segment in the wheel excavators category. The model's dimensions are 7.73m x 2.48m x 3.085m. The bucket capacity of MH 3.6 WT is 0,5m³, which is above average for this type of machine.

Since 2008, this model has included Blade and Aircondition. It has been sold without air Quick hitch hydr., Overload alert and Quick hitch mech. As of 2014. There are more detailed specifications and machine descriptions available in the original New Holland MH 3.6 WT specs data sheet. You can download it for free in English, French, Spanish, Italian and German on LECTURA Specs.

This model can be acquired for a list price between €113000 and €144000. Production of the MH 3.6 WT stopped in 2014. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

The most commonly viewed New Holland models of this type on LECTURA Specs are the WE 150 B pro, WE 170 B pro and WE 190 B pro, and 5 other wheel excavators, which currently range from 15.4t up to 21.5t are also available. Want more detailed specifications? Download the latest New Holland MH 3.6 WT specs data sheet on LECTURA Specs today!

Wheel Excavators New Holland MH 3.6 WT

Technical specs - MH 3.6 WT New Holland

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
12 t
Standard tyres
10.00-20
Bucket capacity
0.5 m³
Boom
VA
Transport length
7.73 m
Transport width
2.48 m
Transport height
3.085 m
Max. Reach horizontal
8.759 m
Dredging depth
4.491 m
Tear-out force
62.9 kN
Model series
MH
Engine manuf.
CNH
Engine type
445TA-MLL
Engine power
84 kW
Displacement
4.5 l
Revolutions at max torque
2000 rpm

More technical details, like: bucket capacity min., bucket capacity max., outrigger stabilisers, bucket width, dipper length, turning radius inside, turning radius outside, travel speed, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke...

More technical details, like: bucket capacity min., bucket capacity max., outrigger stabilisers, bucket width, dipper length, turning radius inside, turning radius outside, travel speed, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, total number of dippers - mono, number of articulated booms, emission rating, engine manufacturer, engine model, rated speed, engine output - net, transmission type, number of tyres - standard, tyre size - standard, overall width, machine width - maximum, wheelbase, rear axle to slew centre, cab height, ground clearance, overall width - stabilisers down, standard dipper length, longest dipper length, ground level reach - articulated boom, maximum dig height - articulated boom, dump clearance height - articulated boom, dig depth - articulated boom, dozer blade - width, fuel tank, slew speed, max bucket breakout, mono boom, number of main pumps, main pumps - maximum flow, boom pressure, operating weight are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Track guidance
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

New Holland MH 3.6 WT FAQ

When was the New Holland MH 3.6 WT manufactured?

The New Holland MH 3.6 WT was manufactured from 2008 to 2014.

How much does the New Holland MH 3.6 WT weigh?

The New Holland MH 3.6 WT weighs 12 tons.

What are the transport dimensions of the New Holland MH 3.6 WT wheel excavator?

The New Holland MH 3.6 WT has a transport length of 7.73 meters, a transport width of 2.48 meters, and a transport height of 3.09 meters.

What are the undercarriage specifications of the New Holland MH 3.6 WT wheel excavator?

The New Holland MH 3.6 WT wheel excavator is equipped with standard tyres sized 10.00-20.

What are the excavation performance specifications of the New Holland MH 3.6 WT wheel excavator?

The New Holland MH 3.6 WT has an adjustable boom, a maximum horizontal reach of 8.759 meters, and a dredging depth of 4.491 meters.

What is the tear-out force of the New Holland MH 3.6 WT wheel excavator?

The New Holland MH 3.6 WT wheel excavator has a tear-out force of 62.9 kN.

What is the bucket capacity of the New Holland MH 3.6 WT wheel excavator?

The bucket capacity of the New Holland MH 3.6 WT wheel excavator is 0.5 cubic meters.

How much is a New Holland MH 3.6 WT Wheel excavator (2008u20132014) worth?

The residual value of the New Holland MH 3.6 WT depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
