A 916 Litronic Liebherr Excavator Specs & Dimensions - (2018 - 2019)

Weight: 17.4t – Standard tyres: 10.00-20 – Bucket capacity: 0.6m³ – Boom: VA – Outrigger stabilisers: 2/42/4-fold – Transport leng…

Weight: 17.4t – Standard tyres: 10.00-20 – Bucket capacity: 0.6m³ – Boom: VA – Outrigger stabilisers: 2/42/4-fold – Transport length: 8.55m

Check out detailed dimensions, specifications, information and technical data for Liebherr A 916 Litronic excavator manufactured between 2018 - 2019. Get more in-depth insight with Liebherr A 916 Litronic digger specifications. See information, like: Weight: 17.4t – Standard tyres: 10.00-20 – Bucket capacity: 0.6m³ – Boom: VA – Outrigger stabilisers: 2/42/4-fold – Transport length: 8.55m and more.

Wheel Excavators Liebherr A 916 Litronic
Wheel Excavators Liebherr A 916 Litronic
Wheel Excavators Liebherr A 916 Litronic
Wheel Excavators Liebherr A 916 Litronic
Wheel Excavators Liebherr A 916 Litronic
Wheel Excavators Liebherr A 916 Litronic
Wheel Excavators Liebherr A 916 Litronic
Wheel Excavators Liebherr A 916 Litronic
Wheel Excavators Liebherr A 916 Litronic
Wheel Excavators Liebherr A 916 Litronic

Visit Liebherr live at

Technical specs - A 916 Litronic Liebherr

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
17.4 t
Standard tyres
10.00-20
Bucket capacity
0.6 m³
Boom
VA
Outrigger stabilisers
2/4 2/4-fold
Transport length
8.55 m
Transport width
2.55 m
Transport height
3.16 m
Max. Reach horizontal
9.25 m
Dredging depth
5.8 m
Tear-out force
69 kN
Bucket width
0.85 m
Travel speed
20 km/h
Model series
A
Engine manuf.
Liebherr
Engine type
D924
Engine power
115 kW
Displacement
4.5 l
Revolutions at max torque
1800 rpm
Emission level
IV

More technical details, like: bucket capacity min., bucket capacity max., dipper length, turning radius inside, turning radius outside, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Blade
Yes
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
No
Track guidance
No
Aircondition
Yes
Quick hitch hydr.
Yes
Quick hitch mech.
No

Download datasheets (PDF)

Liebherr A 916 Litronic FAQ

When was the Liebherr A 916 Litronic manufactured?

The Liebherr A 916 Litronic was manufactured from 2018 to 2019.

How much does the Liebherr A 916 Litronic weigh?

The Liebherr A 916 Litronic weighs 17.4 tons.

What are the transport dimensions of the Liebherr A 916 Litronic wheel excavator?

The Liebherr A 916 Litronic has a transport length of 8.55 meters, a transport width of 2.55 meters, and a transport height of 3.16 meters.

What is the travel speed of the Liebherr A 916 Litronic wheel excavator?

The Liebherr A 916 Litronic has a travel speed of 20 km/h.

What are the undercarriage specifications of the Liebherr A 916 Litronic wheel excavator?

The Liebherr A 916 Litronic is equipped with standard tyres sized 10.00-20 and features 2-fold or 4-fold outrigger stabilisers.

What are the excavation performance specifications of the Liebherr A 916 Litronic wheel excavator?

The Liebherr A 916 Litronic has a dredging depth of 5.8 meters, a maximum horizontal reach of 9.25 meters, and features an adjustable boom.

What is the tear-out force of the Liebherr A 916 Litronic wheel excavator?

The Liebherr A 916 Litronic wheel excavator has a tear-out force of 69 kN.

What are the bucket specifications of the Liebherr A 916 Litronic wheel excavator?

The Liebherr A 916 Litronic wheel excavator has a bucket capacity of 0.6 cubic meters and a bucket width of 0.85 meters.

How much is a Liebherr A 916 Litronic Wheel excavator (2018u20132019) worth?

The residual value of the Liebherr A 916 Litronic depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
