M 825 B Eder Excavator Specs & Dimensions - (1991 - 1995)

Eder is the manufacturer of the wheel excavator model M 825 B. Find and download detailed specs and data sheets for this machine h…

Eder is the manufacturer of the wheel excavator model M 825 B. Find and download detailed specs and data sheets for this machine here.

Equipped with a powerful Deutz engine, this M 825 B 15.3t machine can provide 81kW or 108 horse power for the wheel excavator. The Eder M 825 B can be grouped in the medium sized machine segment in the wheel excavators category. The bucket capacity of M 825 B is 0,8m³, which is above average for this type of machine.

It has been sold without air Quick hitch hydr., Overload alert and Material Handling Excavator as of 1995. There are more detailed specifications and machine descriptions available in the original Eder M 825 B specs data sheet.

The production stopped in 1995, where this M 825 B was available at a new list price between €154000 and €196000. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

The most commonly viewed Eder models of this type on LECTURA Specs are the, and other wheel excavators, which currently range from up to are also available. Want more detailed specifications? Download the latest Eder M 825 B specs data sheet on LECTURA Specs today!

Wheel Excavators Eder M 825 B

Technical specs - M 825 B Eder

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
15.3 t
Standard tyres
10.00-20
Bucket capacity
0.8 m³
Engine manuf.
Deutz
Engine type
BF6L913
Engine power
81 kW

More technical details, like: bucket capacity min., bucket capacity max., boom, outrigger stabilisers, transport length, transport width, transport height, max. reach horizontal, dredging depth, tear-out force, bucket width, dipper length...

More technical details, like: bucket capacity min., bucket capacity max., boom, outrigger stabilisers, transport length, transport width, transport height, max. reach horizontal, dredging depth, tear-out force, bucket width, dipper length, turning radius inside, turning radius outside, travel speed, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Track guidance
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Eder M 825 B FAQ

When was the Eder M 825 B manufactured?

The Eder M 825 B was manufactured from 1991 to 1995.

How much does the Eder M 825 B weigh?

The Eder M 825 B weighs 15.3 tons.

What are the undercarriage specifications of the Eder M 825 B wheel excavator?

The Eder M 825 B wheel excavator is equipped with standard tyres sized 10.00-20.

What is the bucket capacity of the Eder M 825 B wheel excavator?

The bucket capacity of the Eder M 825 B wheel excavator is 0.8 cubic meters.

How much is a Eder M 825 B Wheel excavator (1991u20131995) worth?

The residual value of the Eder M 825 B depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
