    Technical specs - M314F Caterpillar

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

    Weight 15.32 t
    Standard tyres 10.00-20
    Bucket capacity 0.53 m³
    Boom MB
    Outrigger stabilisers 2 2/4-fach
    Transport length 8.25 m
    Transport width 2.545 m
    Transport height 3.28 m
    Max. Reach horizontal 8.28 m
    Dredging depth 5.03 m
    Tear-out force 103 kN
    Bucket width 0.9 m
    Turning radius outside 6.2 m
    Travel speed 37 km/h
    Engine manuf. Caterpillar
    Engine type C4.4 Acert
    Engine power 105 kW
    Engine power 141 HP
    Displacement 4.4 l
    Revolutions at max torque 1400 rpm
    Max. torque 560 Nm
    No. of cylinders 4
    Cylinder bore x stroke 105x127 mm
    Emission level Stage IV
    Bucket capacity min. ###
    Bucket capacity max. ###
    Dipper length ###
    Turning radius inside ###
    Dimension lxwxh ###
    Weight ###
    Number Of Mono Booms ###
    Total Number Of Dippers - Mono ###
    Number Of Articulated Booms ###
    Total Number Of Dippers - Articulated ###
    Dipper Length - Shortest Articulated ###
    Dipper Length - Standard Articulated ###
    Telematics Available ###
    Platform ###
    Emission Rating ###
    Engine Manufacturer ###
    Engine Model ###
    Rated Speed ###
    Engine Output - Net ###
    Transmission Type ###
    Tyre Size - Standard ###
    Number Of Tyres - Standard ###
    Maximum Transport Length - Mono Boom ###
    Transport Height - Over Mono Boom ###
    Overall Width ###
    Wheelbase ###
    Rear Axle To Slew Centre ###
    Cab Height ###
    Ground Clearance ###
    Machine Width - Maximum ###
    Overall Width - Stabilisers Down ###
    Mono Boom Size ###
    Standard Dipper Length ###
    Longest Dipper Length ###
    Ground Level Reach - Mono Boom ###
    Maximum Dig Height - Mono Boom ###
    Dump Clearance Height - Mono Boom ###
    Dig Depth - Mono Boom ###
    Dig Depth - Articulated Boom ###
    Dozer Blade - Width ###
    Fuel Tank ###
    Slew Speed ###
    Sound Level Standard ###
    Sound Level internal ###
    Sound Level External ###
    Max bucket breakout, Mono Boom ###
    Dipper Standard, Boost Tearout Artic ###
    Boom Pressure ###
    Operating Weight ###

    Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

    M314F Caterpillar - Special equipment

    • Diesel particulate filter
    • Blade
    • Cabin adjustment
    • Overload alert
    • Material Handling Excavator
    • Track guidance
    • Aircondition
    • Quick hitch hydr.
    • Quick hitch mech.
