WX160E Case Excavator Specs & Dimensions - (2022 - 2026)

Weight: 18.39t – Standard tyres: 10.00-20 – Bucket capacity: 0.7m³ – Bucket capacity min.: 0.24m³ – Bucket capacity max.: 0.87m³ –…

Weight: 18.39t – Standard tyres: 10.00-20 – Bucket capacity: 0.7m³ – Bucket capacity min.: 0.24m³ – Bucket capacity max.: 0.87m³ – Boom: VA

Check out detailed dimensions, specifications, information and technical data for Case WX160E excavator manufactured between 2022 - 2026. Get more in-depth insight with Case WX160E digger specifications. See information, like: Weight: 18.39t – Standard tyres: 10.00-20 – Bucket capacity: 0.7m³ – Bucket capacity min.: 0.24m³ – Bucket capacity max.: 0.87m³ – Boom: VA and more.

Wheel Excavators Case WX160E

Technical specs - WX160E Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
18.39 t
Standard tyres
10.00-20
Bucket capacity
0.7 m³
Bucket capacity min.
0.24 m³
Bucket capacity max.
0.87 m³
Boom
VA
Outrigger stabilisers
2/4 2/4-fold
Transport length
8.345 m
Transport width
2.53 m
Transport height
3.23 m
Max. Reach horizontal
8.99 m
Dredging depth
5.54 m
Tear-out force
125 kN
Dipper length
2.45 m
Turning radius inside
6.3 m
Travel speed
35 km/h
Model series
E
Engine manuf.
Cummins
Engine type
B4.5
Engine power
127 kW
Displacement
4.5 l
Revolutions at max torque
1500 rpm
Max. torque
780 Nm
No. of cylinders
4
Cylinder bore x stroke
107x124 mm
Emission level
EU V

More technical details, like: bucket width, turning radius outside, dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Blade
Yes
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
No
Track guidance
No
Aircondition
Yes
Quick hitch hydr.
Yes
Quick hitch mech.
No

Case WX160E FAQ

When was the Case WX160E manufactured?

The Case WX160E was first produced in 2022.

How much does the Case WX160E wheel excavator weigh?

The Case WX160E wheel excavator weighs 18.39 tons.

What are the transport dimensions of the Case WX160E wheel excavator?

The Case WX160E has a transport length of 8.345 meters, a transport width of 2.53 meters, and a transport height of 3.23 meters.

What is the travel speed of the Case WX160E wheel excavator?

The Case WX160E has a travel speed of 35 km/h.

What are the undercarriage specifications of the Case WX160E wheel excavator?

The Case WX160E is equipped with 10.00-20 standard tyres and features 2/4-fold outrigger stabilisers.

What is the inside turning radius of the Case WX160E wheel excavator?

The Case WX160E has an inside turning radius of 6.3 meters.

What are the excavation performance specifications of the Case WX160E wheel excavator?

The Case WX160E has a dredging depth of 5.54 meters, a maximum horizontal reach of 8.99 meters, features an adjustable boom, and has a dipper length of 2.45 meters.

What is the tear-out force of the Case WX160E wheel excavator?

The Case WX160E wheel excavator has a tear-out force of 125 kN.

What are the bucket capacity specifications of the Case WX160E wheel excavator?

The Case WX160E wheel excavator has a bucket capacity of 0.7 mu00b3, with a maximum capacity of 0.87 mu00b3 and a minimum capacity of 0.24 mu00b3.
