1088 P 2A Case Poclain Excavator Specs & Dimensions - (1989 - 1993)

The 1088 P 2A wheel excavator model is manufactured by Case Poclain. Find and download detailed specs and data sheets for this mac…

The 1088 P 2A wheel excavator model is manufactured by Case Poclain. Find and download detailed specs and data sheets for this machine here.

Equipped with a powerful case engine, this 1088 P 2A 18.5t machine can provide 95kW or 127 horse power for the wheel excavator. The 1088 P 2A is categorised in the medium sized machine segment in the wheel excavators category. The model's dimensions are 8.85m x 2.49m x 3.27m. The bucket of 1088 P 2A has a capacity of 1,15m³ which is average for this type of machine.

It does not include Aircondition, Quick hitch hydr. And Diesel particulate filter. There are more detailed specifications and machine descriptions available in the original Case Poclain 1088 P 2A specs data sheet.

This model can be acquired for a list price between €168000 and €214000. Production of the 1088 P 2A stopped in 1993. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

Case Poclain currently produces other wheel excavators, which range from up to - the most visited on LECTURA Specs are. Want more detailed specifications? Download the latest Case Poclain 1088 P 2A specs data sheet on LECTURA Specs today!

Wheel Excavators Case Poclain 1088 P 2A

Technical specs - 1088 P 2A Case Poclain

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
18.5 t
Standard tyres
11.00-20
Bucket capacity
1.15 m³
Transport length
8.85 m
Transport width
2.49 m
Transport height
3.27 m
Model series
P
Engine manuf.
Case
Engine type
6T 590
Engine power
95 kW

More technical details, like: bucket capacity min., bucket capacity max., boom, outrigger stabilisers, max. reach horizontal, dredging depth, tear-out force, bucket width, dipper length, turning radius inside, turning radius outside, travel speed...

More technical details, like: bucket capacity min., bucket capacity max., boom, outrigger stabilisers, max. reach horizontal, dredging depth, tear-out force, bucket width, dipper length, turning radius inside, turning radius outside, travel speed, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Track guidance
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Case Poclain 1088 P 2A FAQ

When was the Case Poclain 1088 P 2A manufactured?

The Case Poclain 1088 P 2A was manufactured from 1989 to 1993.

How much does the Case Poclain 1088 P 2A weigh?

The Case Poclain 1088 P 2A weighs 18.5 tons.

What are the transport dimensions of the Case Poclain 1088 P 2A wheel excavator?

The transport dimensions of the Case Poclain 1088 P 2A are 8.85 meters in length, 2.49 meters in width, and 3.27 meters in height.

What is the size of the standard tyres on the Case Poclain 1088 P 2A?

The Case Poclain 1088 P 2A has standard tyres sized 11.00-20.

What is the bucket capacity of the Case Poclain 1088 P 2A wheel excavator?

The bucket capacity of the Case Poclain 1088 P 2A wheel excavator is 1.15 cubic meters.

How much is a Case Poclain 1088 P 2A Wheel excavator (1989u20131993) worth?

The residual value of the Case Poclain 1088 P 2A depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
