TM 200 Atlas Excavator Specs & Dimensions - (2008 - 2010)

Manufactured by Atlas, this is the TM 200 wheel excavator. Find and download detailed specs and data sheets for this machine here.…

Manufactured by Atlas, this is the TM 200 wheel excavator. Find and download detailed specs and data sheets for this machine here.

The Atlas TM 200 is a 18t machine with Deutz engine which powers this model with up to 105kW or 140 horse power. This Atlas wheel excavator belongs to the medium sized machine segment in the wheel excavators category. The bucket capacity of TM 200 is 1m³, which is above average for this type of machine.

The Atlas TM 200 has been equipped and sold with Aircondition, Material Handling Excavator and Overload alert. It has been sold without air Quick hitch mech., Diesel particulate filter and Cabin adjustment as of 2010. There are more detailed specifications and machine descriptions available in the original Atlas TM 200 specs data sheet.

The production stopped in 2010, where this TM 200 was available at a new list price between €233000 and €297000. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

Atlas currently produces 15 other wheel excavators, which range from 14.9t up to 52t - the most visited on LECTURA Specs are 1604 ZW, 1404 ZW, 350 MH. Want more detailed specifications? Download the latest Atlas TM 200 specs data sheet on LECTURA Specs today!

Wheel Excavators Atlas TM 200

Visit Atlas live at

Technical specs - TM 200 Atlas

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
18 t
Standard tyres
10.00-20
Bucket capacity
1 m³
Boom
MB
Outrigger stabilisers
4 2/4-fold
Max. Reach horizontal
10.25 m
Dredging depth
3.25 m
Model series
TM
Engine manuf.
Deutz
Engine type
TCD2012 L06
Engine power
105 kW
Displacement
6.057 l
Revolutions at max torque
2000 rpm

More technical details, like: bucket capacity min., bucket capacity max., transport length, transport width, transport height, tear-out force, bucket width, dipper length, turning radius inside, turning radius outside, travel speed, dimension lxwxh...

More technical details, like: bucket capacity min., bucket capacity max., transport length, transport width, transport height, tear-out force, bucket width, dipper length, turning radius inside, turning radius outside, travel speed, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Blade
No
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
Yes
Track guidance
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Atlas TM 200 FAQ

When was the Atlas TM 200 manufactured?

The Atlas TM 200 was manufactured from 2008 to 2010.

How much does the Atlas TM 200 wheel excavator weigh?

The Atlas TM 200 wheel excavator weighs 18 tons.

What are the undercarriage specifications of the Atlas TM 200 wheel excavator?

The Atlas TM 200 wheel excavator is equipped with 10.00-20 standard tyres and has 4 outrigger stabilisers.

What are the excavation performance specifications of the Atlas TM 200 wheel excavator?

The Atlas TM 200 wheel excavator has a dredging depth of 3.25 meters, a maximum horizontal reach of 10.25 meters, and is equipped with a monobloc boom.

What is the bucket capacity of the Atlas TM 200 wheel excavator?

The bucket capacity of the Atlas TM 200 wheel excavator is 1 cubic meter.

How much is a Atlas TM 200 Wheel excavator (2008u20132010) worth?

The residual value of the Atlas TM 200 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
