150 W Atlas Excavator Specs & Dimensions - (2014 - 2019)

Manufactured by Atlas, this is the 150 W wheel excavator. Find and download detailed specs and data sheets for this machine here. …

Manufactured by Atlas, this is the 150 W wheel excavator. Find and download detailed specs and data sheets for this machine here.

This wheel excavator is built to provide up to 95kW or 127 horse power, delivered from its powerful Deutz engine to the 16t 150 W machine. The Atlas 150 W can be grouped in the medium sized machine segment in the wheel excavators category. The model's dimensions are 7.71m x 2.49m x 3.08m. The bucket of 150 W has a capacity of 0,82m³ which is average for this type of machine.

The Atlas 150 W has been equipped and sold with Blade, Overload alert and Aircondition. It does not include Material Handling Excavator, Track guidance and Quick hitch hydr.. There are more detailed specifications and machine descriptions available in the original Atlas 150 W specs data sheet. Available in English, German and French, LECTURA Specs offers a free download of highly detailed specifications and machine descriptions of this model.

This model can be acquired for a list price between €198000 and €251000. Production of the 150 W continues in 2017. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

At present, 14 other wheel excavators, which range from 14.9t up to 52t are produced by Atlas. Of these, 1404 ZW, 1604 ZW and also 350 MH are the most frequently visited on LECTURA Specs. Ranked in the LECTURA index at #95, this 150 W wheel excavator has models that date from 2014 to 2017. Want more detailed specifications? Download the latest Atlas 150 W specs data sheet on LECTURA Specs today!

Wheel Excavators Atlas 150 W
Wheel Excavators Atlas 150 W
Wheel Excavators Atlas 150 W
Wheel Excavators Atlas 150 W
Wheel Excavators Atlas 150 W
Wheel Excavators Atlas 150 W

Visit Atlas live at

Technical specs - 150 W Atlas

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
15 t
Standard tyres
10.00-20
Bucket capacity
0.82 m³
Boom
VA
Outrigger stabilisers
2/4 2/4-fold
Transport length
7.71 m
Transport width
2.49 m
Transport height
3.08 m
Max. Reach horizontal
8.7 m
Dredging depth
5.1 m
Tear-out force
82 kN
Bucket width
1 m
Travel speed
20 km/h

More technical details, like: bucket capacity min., bucket capacity max., dipper length, turning radius inside, turning radius outside, model series, engine manuf., engine type, engine power, dimension lxwxh, displacement, revolutions at max torque...

More technical details, like: bucket capacity min., bucket capacity max., dipper length, turning radius inside, turning radius outside, model series, engine manuf., engine type, engine power, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level, number of mono booms, total number of dippers - mono, number of articulated booms, total number of dippers - articulated, dipper length - longest articulated, dipper length - standard articulated, telematics available, platform, emission rating, engine manufacturer, engine model, rated speed, engine output - net, transmission type, number of tyres - standard, tyre size - standard, maximum transport length - mono boom, overall width, wheelbase, rear axle to slew centre, tailswing radius, cab height, ground clearance, overall width - stabilisers down, mono boom size, standard dipper length, longest dipper length, ground level reach - mono boom, maximum dig height - mono boom, dump clearance height - mono boom, dig depth - mono boom, ground level reach - articulated boom, maximum dig height - articulated boom, dump clearance height - articulated boom, dig depth - articulated boom, dozer blade - width, fuel tank, slew speed, max bucket breakout, mono boom, max bucket breakout, artic boom, main pumps - maximum flow, boom pressure, operating weight are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Blade
Yes
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
No
Track guidance
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Atlas 150 W FAQ

When was the Atlas 150 W manufactured?

The Atlas 150 W was manufactured from 2014 to 2019.

How much does the Atlas 150 W wheel excavator weigh?

The Atlas 150 W wheel excavator weighs 15 tons.

What are the transport dimensions of the Atlas 150 W wheel excavator?

The Atlas 150 W wheel excavator has a transport length of 7.71 meters, a transport width of 2.49 meters, and a transport height of 3.08 meters.

What is the travel speed of the Atlas 150 W wheel excavator?

The Atlas 150 W wheel excavator has a travel speed of 20 km/h.

What are the undercarriage specifications of the Atlas 150 W wheel excavator?

The Atlas 150 W wheel excavator is equipped with standard 10.00-20 tyres and features 2/4-fold outrigger stabilisers.

What are the excavation performance specifications of the Atlas 150 W wheel excavator?

The Atlas 150 W wheel excavator has a dredging depth of 5.1 meters, a maximum horizontal reach of 8.7 meters, and features an adjustable boom.

What is the tear-out force of the Atlas 150 W wheel excavator?

The Atlas 150 W wheel excavator has a tear-out force of 82 kN.

What are the bucket specifications of the Atlas 150 W wheel excavator?

The Atlas 150 W wheel excavator has a bucket capacity of 0.82 cubic meters and a bucket width of 1 meter.

How much is a Atlas 150 W Wheel excavator (2014u20132019) worth?

The residual value of the Atlas 150 W depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
