870 M Sennebogen Excavator Specs & Dimensions - (2015 - 2019)

The 870 M wheel excavator model is manufactured by Sennebogen. Find and download detailed specs and data sheets for this machine h…

The 870 M wheel excavator model is manufactured by Sennebogen. Find and download detailed specs and data sheets for this machine here.

The Sennebogen 870 M is a 66t machine with Caterpillar engine which powers this model with up to 313kW or 419 horse power. The Sennebogen 870 M can be grouped in the biggest machine segment in the wheel excavators category. The model's dimensions are 7.2m x 3.65m x 3.6m. The bucket capacity of 870 M is 1,4m³, which is above average for this type of machine.

The Sennebogen 870 M has been equipped and sold with Aircondition, Material Handling Excavator and Overload alert. It has been sold without air Track guidance, Quick hitch hydr. And Quick hitch mech. As of 2017. There are more detailed specifications and machine descriptions available in the original Sennebogen 870 M specs data sheet.

This model can be acquired for a list price between €1098000 and €1397000. Production of the 870 M continues in 2017. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

The most commonly viewed Sennebogen models of this type on LECTURA Specs are the 825 M, 850 M and 821 M, and 13 other wheel excavators, which currently range from 16.9t up to 165t are also available. Having been in production from 2015 to 2017, the 870 M wheel excavator ranks in the LECTURA index at #90. Want more detailed specifications? Download the latest Sennebogen 870 M specs data sheet on LECTURA Specs today!

Wheel Excavators Sennebogen 870 M

Visit Sennebogen live at

Technical specs - 870 M Sennebogen

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
66 t
Standard tyres
14.00-24
Bucket capacity
1.4 m³
Boom
UA
Outrigger stabilisers
2/4 2/4-fold
Transport length
7.2 m
Transport width
3.65 m
Transport height
3.6 m
Max. Reach horizontal
20 m
Dredging depth
5.3 m
Travel speed
10 km/h
Model series
M
Engine manuf.
Caterpillar
Engine type
C11
Engine power
313 kW

More technical details, like: bucket capacity min., bucket capacity max., tear-out force, bucket width, dipper length, turning radius inside, turning radius outside, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders...

More technical details, like: bucket capacity min., bucket capacity max., tear-out force, bucket width, dipper length, turning radius inside, turning radius outside, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Buy full specs

Special equipment

Diesel particulate filter
No
Blade
No
Cabin adjustment
Yes
Overload alert
Yes
Material Handling Excavator
Yes
Track guidance
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Sennebogen 870 M FAQ

When was the Sennebogen 870 M manufactured?

The Sennebogen 870 M was manufactured from 2015 to 2019.

How much does the Sennebogen 870 M weigh?

The Sennebogen 870 M weighs 66 tons.

What are the transport dimensions of the Sennebogen 870 M wheel excavator?

The Sennebogen 870 M has a transport length of 7.2 meters, a transport width of 3.65 meters, and a transport height of 3.6 meters.

What is the travel speed of the Sennebogen 870 M wheel excavator?

The Sennebogen 870 M has a travel speed of 10 km/h.

What are the undercarriage specifications of the Sennebogen 870 M wheel excavator?

The Sennebogen 870 M is equipped with 14.00-24 standard tyres and has 2/4-fold outrigger stabilisers.

What are the excavation performance specifications of the Sennebogen 870 M wheel excavator?

The Sennebogen 870 M has a dredging depth of 5.3 meters, a maximum horizontal reach of 20 meters, and is equipped with a material handling boom.

What is the bucket capacity of the Sennebogen 870 M wheel excavator?

The Sennebogen 870 M wheel excavator has a bucket capacity of 1.4 cubic meters.

How much is a Sennebogen 870 M Wheel excavator (2015u20132019) worth?

The residual value of the Sennebogen 870 M depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
