821 M Sennebogen Excavator Specs & Dimensions - (2011 - 2019)

Model rating
9,00 / 10

Manufactured by Sennebogen, this is the 821 M wheel excavator. Find and download detailed specs and data sheets for this machine h…

Manufactured by Sennebogen, this is the 821 M wheel excavator. Find and download detailed specs and data sheets for this machine here.

This wheel excavator is built to provide up to 97kW or 130 horse power, delivered from its powerful Cummins engine to the 22t 821 M machine. The Sennebogen 821 M can be grouped in the biggest machine segment in the wheel excavators category. The model's dimensions are 4.73m x 2.55m x 3.18m. The bucket of 821 M has a capacity of 0,6m³ which is average for this type of machine.

The 821 M is manufactured and distributed with Overload alert and Material Handling Excavator. Diesel particulate filter, Quick hitch mech. And Track guidance are not provided on this model as of 2017. There are more detailed specifications and machine descriptions available in the original Sennebogen 821 M specs data sheet. You can download it for free in English and German on LECTURA Specs.

The production is still going in 2017, where this 821 M is available at a new list price between €235000 and €299000. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

At present, 13 other wheel excavators, which range from 16.9t up to 165t are produced by Sennebogen. Of these, 840 M, 850 M and also 825 M are the most frequently visited on LECTURA Specs. This 821 M wheel excavator, which has been in production between 2011 and 2017 ranks in the LECTURA index at #26. Want more detailed specifications? Download the latest Sennebogen 821 M specs data sheet on LECTURA Specs today!

Wheel Excavators Sennebogen 821 M
Wheel Excavators Sennebogen 821 M
Wheel Excavators Sennebogen 821 M
Wheel Excavators Sennebogen 821 M
Wheel Excavators Sennebogen 821 M
Wheel Excavators Sennebogen 821 M
Wheel Excavators Sennebogen 821 M
Wheel Excavators Sennebogen 821 M
Wheel Excavators Sennebogen 821 M
Wheel Excavators Sennebogen 821 M

Visit Sennebogen live at

Technical specs - 821 M Sennebogen

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
22 t
Standard tyres
10.00-20
Bucket capacity
0.6 m³
Boom
UA
Outrigger stabilisers
2/4 2/4-fold
Transport length
4.73 m
Transport width
2.55 m
Transport height
3.18 m
Max. Reach horizontal
12 m
Travel speed
20 km/h
Model series
M
Engine manuf.
Cummins
Engine type
QSB4.5-C130
Engine power
97 kW
Emission level
T3

More technical details, like: bucket capacity min., bucket capacity max., dredging depth, tear-out force, bucket width, dipper length, turning radius inside, turning radius outside, dimension lxwxh, displacement, revolutions at max torque, max. torque...

More technical details, like: bucket capacity min., bucket capacity max., dredging depth, tear-out force, bucket width, dipper length, turning radius inside, turning radius outside, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Blade
No
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
Yes
Track guidance
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Sennebogen 821 M FAQ

When was the Sennebogen 821 M manufactured?

The Sennebogen 821 M was manufactured from 2011 to 2019.

How much does the Sennebogen 821 M weigh?

The Sennebogen 821 M weighs 22 tons.

What are the transport dimensions of the Sennebogen 821 M wheel excavator?

The Sennebogen 821 M has a transport length of 4.73 meters, a transport width of 2.55 meters, and a transport height of 3.18 meters.

What is the travel speed of the Sennebogen 821 M wheel excavator?

The Sennebogen 821 M wheel excavator has a travel speed of 20 km/h.

What are the undercarriage specifications of the Sennebogen 821 M wheel excavator?

The Sennebogen 821 M is equipped with standard tyres sized 10.00-20 and features 2/4 outrigger stabilisers.

What are the maximum horizontal reach and boom type of the Sennebogen 821 M wheel excavator?

The Sennebogen 821 M has a maximum horizontal reach of 12 meters and is equipped with a material handling boom.

What is the bucket capacity of the Sennebogen 821 M wheel excavator?

The Sennebogen 821 M wheel excavator has a bucket capacity of 0.6 cubic meters.

How much is a Sennebogen 821 M Wheel excavator (2011u20132019) worth?

The residual value of the Sennebogen 821 M depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
