REX74CW RHINO Excavator Specs & Dimensions - (2017 - 2026)

Weight: 7.4t – Bucket capacity: 0.2m³ – Boom: MB – Transport length: 6.1m – Transport width: 2.085m – Transport height: 2.905m…

Weight: 7.4t – Bucket capacity: 0.2m³ – Boom: MB – Transport length: 6.1m – Transport width: 2.085m – Transport height: 2.905m

Check out detailed dimensions, specifications, information and technical data for RHINO REX74CW excavator manufactured between 2017 - 2026. Get more in-depth insight with RHINO REX74CW digger specifications. See information, like: Weight: 7.4t – Bucket capacity: 0.2m³ – Boom: MB – Transport length: 6.1m – Transport width: 2.085m – Transport height: 2.905m and more.

Wheel Excavators RHINO REX74CW

Technical specs - REX74CW RHINO

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
7.4 t
Bucket capacity
0.2 m³
Boom
MB
Transport length
6.1 m
Transport width
2.085 m
Transport height
2.905 m
Max. Reach horizontal
5.78 m
Dredging depth
2.99 m
Tear-out force
53 kN
Model series
REX
Engine manuf.
RHINO
Engine type
A498BPG
Engine power
45 kW
Displacement
3.2 l
No. of cylinders
4
Emission level
Tier 2

More technical details, like: standard tyres, bucket capacity min., bucket capacity max., outrigger stabilisers, bucket width, dipper length, turning radius inside, turning radius outside, travel speed, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Track guidance
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

RHINO REX74CW FAQ

When was the RHINO REX74CW manufactured?

The RHINO REX74CW was first produced in 2017.

How much does the RHINO REX74CW wheel excavator weigh?

The RHINO REX74CW wheel excavator weighs 7.4 tons.

What are the transport dimensions of the RHINO REX74CW wheel excavator?

The RHINO REX74CW has a transport length of 6.1 meters, a transport width of 2.09 meters, and a transport height of 2.91 meters.

What are the excavation performance specifications of the RHINO REX74CW wheel excavator?

The RHINO REX74CW wheel excavator has a dredging depth of 2.99 meters, a maximum horizontal reach of 5.78 meters, and is equipped with a monobloc boom.

What is the tear-out force of the RHINO REX74CW wheel excavator?

The RHINO REX74CW wheel excavator has a tear-out force of 53 kN.

What is the bucket capacity of the RHINO REX74CW wheel excavator?

The RHINO REX74CW wheel excavator has a bucket capacity of 0.2 cubic meters.

How much is a RHINO REX74CW Wheel excavator (2017u20132025) worth?

The residual value of the RHINO REX74CW depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
