MH 3.5 O&K Excavator Specs & Dimensions - (2001 - 2005)

O&K is the manufacturer of the wheel excavator model MH 3.5. Find and download detailed specs and data sheets for this machine…

O&K is the manufacturer of the wheel excavator model MH 3.5. Find and download detailed specs and data sheets for this machine here.

Equipped with a powerful Perkins engine, this MH 3.5 12t machine can provide 67kW or 89 horse power for the wheel excavator. The MH 3.5 is categorised in the smallest machine segment in the wheel excavators category. The model's dimensions are 6.705m x 2.48m x 3.03m. The bucket of MH 3.5 has a capacity of 0,5m³ which is average for this type of machine.

Since 2001, this model has included Blade. Aircondition, Overload alert and Cabin adjustment are not provided on this model as of 2005. There are more detailed specifications and machine descriptions available in the original O&K MH 3.5 specs data sheet. You can download it for free in German on LECTURA Specs.

This model can be acquired for a list price between €111000 and €142000. Production of the MH 3.5 stopped in 2005. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

The most commonly viewed O&K models of this type on LECTURA Specs are the, and other wheel excavators, which currently range from up to are also available. Want more detailed specifications? Download the latest O&K MH 3.5 specs data sheet on LECTURA Specs today!

Wheel Excavators O&K MH 3.5

Technical specs - MH 3.5 O&K

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
12 t
Standard tyres
10.00-20
Bucket capacity
0.5 m³
Boom
VA
Transport length
6.71 m
Transport width
2.48 m
Transport height
3.03 m
Max. Reach horizontal
8.4 m
Dredging depth
4.585 m
Tear-out force
49.5 kN
Bucket width
1 m
Model series
MH
Engine manuf.
Perkins
Engine type
1004.4T
Engine power
67 kW
Displacement
3.99 l
Revolutions at max torque
1900 rpm

More technical details, like: bucket capacity min., bucket capacity max., outrigger stabilisers, dipper length, turning radius inside, turning radius outside, travel speed, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Track guidance
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

O&K MH 3.5 FAQ

When was the O&K MH 3.5 manufactured?

The O&K MH 3.5 was manufactured from 2001 to 2005.

How much does the O&K MH 3.5 wheel excavator weigh?

The O&K MH 3.5 wheel excavator weighs 12 tons.

What are the transport dimensions of the O&K MH 3.5 wheel excavator?

The O&K MH 3.5 has a transport length of 6.71 meters, a transport width of 2.48 meters, and a transport height of 3.03 meters.

What is the standard tyre size of the O&K MH 3.5 wheel excavator?

The O&K MH 3.5 wheel excavator has standard tyres sized 10.00-20.

What are the excavation performance specifications of the O&K MH 3.5 wheel excavator?

The O&K MH 3.5 wheel excavator has a dredging depth of 4.585 meters, a maximum horizontal reach of 8.4 meters, and features an adjustable boom.

What is the tear-out force of the O&K MH 3.5 wheel excavator?

The O&K MH 3.5 wheel excavator has a tear-out force of 49.5 kN.

What are the bucket specifications of the O&K MH 3.5 wheel excavator?

The O&K MH 3.5 wheel excavator has a bucket capacity of 0.5 cubic meters and a bucket width of 1 meter.
