812 2 P Kramer Excavator Specs & Dimensions - (1995 - 1999)

Manufactured by Kramer, this is the 812 2 P wheel excavator. Find and download detailed specs and data sheets for this machine her…

Manufactured by Kramer, this is the 812 2 P wheel excavator. Find and download detailed specs and data sheets for this machine here.

This wheel excavator is built to provide up to 72kW or 96 horse power, delivered from its powerful Perkins engine to the 11.9t 812 2 P machine. The Kramer 812 2 P can be grouped in the smallest machine segment in the wheel excavators category. The bucket capacity of 812 2 P is 0,5m³, which is above average for this type of machine.

Since 1995, this model has included Blade. Cabin adjustment, Quick hitch hydr. And Diesel particulate filter are not provided on this model as of 1999. There are more detailed specifications and machine descriptions available in the original Kramer 812 2 P specs data sheet.

This model can be acquired for a list price between €119000 and €152000. Production of the 812 2 P stopped in 1999. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

Kramer currently produces other wheel excavators, which range from up to - the most visited on LECTURA Specs are. Want more detailed specifications? Download the latest Kramer 812 2 P specs data sheet on LECTURA Specs today!

Wheel Excavators Kramer 812 2 P

Technical specs - 812 2 P Kramer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
11.9 t
Standard tyres
10.00-20
Bucket capacity
0.5 m³
Outrigger stabilisers
2 2/4-fold
Engine manuf.
Perkins
Engine type
1004.4T
Engine power
72 kW

More technical details, like: bucket capacity min., bucket capacity max., boom, transport length, transport width, transport height, max. reach horizontal, dredging depth, tear-out force, bucket width, dipper length, turning radius inside...

More technical details, like: bucket capacity min., bucket capacity max., boom, transport length, transport width, transport height, max. reach horizontal, dredging depth, tear-out force, bucket width, dipper length, turning radius inside, turning radius outside, travel speed, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level, number of articulated booms, engine manufacturer, engine model, rated speed, transmission type, number of tyres - standard, tyre size - standard, transport height - over mono boom, machine width - maximum, wheelbase, rear axle to slew centre, tailswing radius, cab height, ground clearance, ground level reach - articulated boom, maximum dig height - articulated boom, dump clearance height - articulated boom, dig depth - articulated boom, dozer blade - width, fuel tank, slew speed, max bucket breakout, mono boom, number of main pumps, main pumps - maximum flow, boom pressure, operating weight are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Track guidance
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Kramer 812 2 P FAQ

When was the Kramer 812 2 P manufactured?

The Kramer 812 2 P was manufactured from 1995 to 1999.

How much does the Kramer 812 2 P weigh?

The Kramer 812 2 P weighs 11.9 tons.

What are the undercarriage specifications of the Kramer 812 2 P wheel excavator?

The Kramer 812 2 P is equipped with 10.00-20 standard tyres and has 2 outrigger stabilisers.

What is the bucket capacity of the Kramer 812 2 P wheel excavator?

The Kramer 812 2 P wheel excavator has a bucket capacity of 0.5 cubic meters.

How much is a Kramer 812 2 P Wheel excavator (1995u20131999) worth?

The residual value of the Kramer 812 2 P depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
