Hydradig 110W JCB Excavator Specs & Dimensions - (2021 - 2026)

Weight: 11.46t – Standard tyres: 315/70-22.5 – Bucket capacity: 0.15m³ – Boom: VA – Outrigger stabilisers: 22/4-fold – Transport l…

Weight: 11.46t – Standard tyres: 315/70-22.5 – Bucket capacity: 0.15m³ – Boom: VA – Outrigger stabilisers: 22/4-fold – Transport length: 7.75m

Check out detailed dimensions, specifications, information and technical data for JCB Hydradig 110W excavator manufactured between 2021 - 2026. Get more in-depth insight with JCB Hydradig 110W digger specifications. See information, like: Weight: 11.46t – Standard tyres: 315/70-22.5 – Bucket capacity: 0.15m³ – Boom: VA – Outrigger stabilisers: 22/4-fold – Transport length: 7.75m and more.

Wheel Excavators JCB Hydradig 110W
Wheel Excavators JCB Hydradig 110W
Wheel Excavators JCB Hydradig 110W
Wheel Excavators JCB Hydradig 110W
Wheel Excavators JCB Hydradig 110W
Wheel Excavators JCB Hydradig 110W
Wheel Excavators JCB Hydradig 110W
Wheel Excavators JCB Hydradig 110W
Wheel Excavators JCB Hydradig 110W
Wheel Excavators JCB Hydradig 110W
Wheel Excavators JCB Hydradig 110W
Wheel Excavators JCB Hydradig 110W
Wheel Excavators JCB Hydradig 110W
Wheel Excavators JCB Hydradig 110W

Visit JCB live at

Technical specs - Hydradig 110W JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
11.46 t
Standard tyres
315/70-22.5
Bucket capacity
0.15 m³
Boom
VA
Outrigger stabilisers
2 2/4-fold
Transport length
7.75 m
Transport width
2.42 m
Transport height
3.3 m
Max. Reach horizontal
7.53 m
Dredging depth
4.16 m
Tear-out force
42.3 kN
Bucket width
0.5 m
Dipper length
2 m
Turning radius outside
4.51 m
Travel speed
40 km/h
Model series
Hydradig
Engine manuf.
JCB
Engine type
DieselMax
Engine power
81 kW
Displacement
4.8 l
Revolutions at max torque
1450 rpm
No. of cylinders
4
Emission level
V

More technical details, like: bucket capacity min., bucket capacity max., turning radius inside, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Blade
Yes
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
Yes
Track guidance
No
Aircondition
Yes
Quick hitch hydr.
Yes
Quick hitch mech.
Yes

JCB Hydradig 110W FAQ

When was the JCB Hydradig 110W manufactured?

The JCB Hydradig 110W was first produced in 2021.

How much does the JCB Hydradig 110W weigh?

The JCB Hydradig 110W weighs 11.46 tons.

What are the transport dimensions of the JCB Hydradig 110W?

The JCB Hydradig 110W has a transport length of 7.75 meters, a transport width of 2.42 meters, and a transport height of 3.3 meters.

What is the travel speed of the JCB Hydradig 110W wheel excavator?

The JCB Hydradig 110W has a travel speed of 40 km/h.

What are the undercarriage specifications of the JCB Hydradig 110W wheel excavator?

The JCB Hydradig 110W is equipped with 315/70-22.5 standard tyres and has two 2-fold outrigger stabilisers.

What is the turning radius of the JCB Hydradig 110W wheel excavator?

The JCB Hydradig 110W has an outside turning radius of 4.51 meters.

What are the excavation performance specifications of the JCB Hydradig 110W wheel excavator?

The JCB Hydradig 110W has an adjustable boom, a dredging depth of 4.16 meters, a maximum horizontal reach of 7.53 meters, and a dipper length of 2 meters.

What is the tear-out force of the JCB Hydradig 110W?

The JCB Hydradig 110W has a tear-out force of 42.3 kN.

What are the specifications of the primary work tool bucket on the JCB Hydradig 110W?

The primary work tool bucket of the JCB Hydradig 110W has a capacity of 0.15 cubic meters and a width of 0.5 meters.

How much is a JCB Hydradig 110W Wheel excavator (2021u20132025) worth?

The residual value of the JCB Hydradig 110W depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
