HW210A Hyundai Excavator Specs & Dimensions - (2021 - 2026)

Weight: 22.17t – Standard tyres: 10.00-20-14PR – Boom: VA – Outrigger stabilisers: 22/4-fold – Transport length: 7.09m – Transport…

Weight: 22.17t – Standard tyres: 10.00-20-14PR – Boom: VA – Outrigger stabilisers: 22/4-fold – Transport length: 7.09m – Transport width: 2.53m

Check out detailed dimensions, specifications, information and technical data for Hyundai HW210A excavator manufactured between 2021 - 2026. Get more in-depth insight with Hyundai HW210A digger specifications. See information, like: Weight: 22.17t – Standard tyres: 10.00-20-14PR – Boom: VA – Outrigger stabilisers: 22/4-fold – Transport length: 7.09m – Transport width: 2.53m and more.

Wheel Excavators Hyundai HW210A
Wheel Excavators Hyundai HW210A
Wheel Excavators Hyundai HW210A
Wheel Excavators Hyundai HW210A
Wheel Excavators Hyundai HW210A
Wheel Excavators Hyundai HW210A
Wheel Excavators Hyundai HW210A
Wheel Excavators Hyundai HW210A
Wheel Excavators Hyundai HW210A
Wheel Excavators Hyundai HW210A

Visit Hyundai live at

Technical specs - HW210A Hyundai

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
22.17 t
Standard tyres
10.00-20-14PR
Boom
VA
Outrigger stabilisers
2 2/4-fold
Transport length
7.09 m
Transport width
2.53 m
Transport height
3.99 m
Max. Reach horizontal
9.97 m
Dredging depth
6.43 m
Tear-out force
151 kN
Dipper length
2.4 m
Turning radius outside
6,69 m
Travel speed
28,4 km/h
Model series
HW
Engine manuf.
Cummins
Engine type
B6.7
Engine power
145 kW
Displacement
6.7 l
Revolutions at max torque
2200 rpm
Max. torque
881/1300 Nm
No. of cylinders
6
Cylinder bore x stroke
107x124 mm
Emission level
Tier 4f / EU V

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, turning radius inside, dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Track guidance
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Hyundai HW210A FAQ

When was the Hyundai HW210A manufactured?

The Hyundai HW210A was first produced in 2021.

How much does the Hyundai HW210A wheel excavator weigh?

The Hyundai HW210A wheel excavator weighs 22.17 tons.

What are the transport dimensions of the Hyundai HW210A wheel excavator?

The Hyundai HW210A has a transport length of 7.09 meters, a transport width of 2.53 meters, and a transport height of 3.99 meters.

What is the travel speed of the Hyundai HW210A wheel excavator?

The Hyundai HW210A wheel excavator has a travel speed of 284 km/h.

What are the undercarriage specifications of the Hyundai HW210A wheel excavator?

The Hyundai HW210A is equipped with standard tyres sized 10.00-20-14PR and features 2 outrigger stabilisers.

What is the turning radius of the Hyundai HW210A wheel excavator?

The Hyundai HW210A wheel excavator has an outside turning radius of 669 meters.

What are the excavation performance specifications of the Hyundai HW210A wheel excavator?

The Hyundai HW210A has a dredging depth of 6.43 meters, a maximum horizontal reach of 9.97 meters, features an adjustable boom, and has a dipper length of 2.4 meters.

What is the tear-out force of the Hyundai HW210A wheel excavator?

The Hyundai HW210A wheel excavator has a tear-out force of 151 kN.

How much is a Hyundai HW210A Wheel excavator (2021u20132025) worth?

The residual value of the Hyundai HW210A depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
