B75W Yanmar Excavator Specs & Dimensions - (2019 - 2024)

Weight: 8t – Bucket capacity: 0.303m³ – Transport length: 5.21m – Transport width: 2.19m – Transport height: 3.595m – Max. Reach h…

Weight: 8t – Bucket capacity: 0.303m³ – Transport length: 5.21m – Transport width: 2.19m – Transport height: 3.595m – Max. Reach horizontal: 7.29m

Check out detailed dimensions, specifications, information and technical data for Yanmar B75W excavator manufactured between 2019 - 2024. Get more in-depth insight with Yanmar B75W digger specifications. See information, like: Weight: 8t – Bucket capacity: 0.303m³ – Transport length: 5.21m – Transport width: 2.19m – Transport height: 3.595m – Max. Reach horizontal: 7.29m and more.

Wheel Excavators Yanmar B75W

Technical specs - B75W Yanmar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
8 t
Bucket capacity
0.303 m³
Transport length
5.21 m
Transport width
2.19 m
Transport height
3.595 m
Max. Reach horizontal
7.29 m
Dredging depth
3.43 m
Tear-out force
38 kN
Travel speed
30 km/h
Model series
B
Engine manuf.
Deutz
Engine type
TCD 2.9 L4
Engine power
55.4 kW
Displacement
2.9 l
Revolutions at max torque
1600 rpm
Max. torque
300 Nm
No. of cylinders
4
Emission level
TIER 4 f

More technical details, like: standard tyres, bucket capacity min., bucket capacity max., boom, outrigger stabilisers, bucket width, dipper length, turning radius inside, turning radius outside, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Track guidance
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Yanmar B75W FAQ

When was the Yanmar B75W manufactured?

The Yanmar B75W was manufactured from 2019 to 2024.

How much does the Yanmar B75W wheel excavator weigh?

The Yanmar B75W wheel excavator weighs 8 tons.

What are the transport dimensions of the Yanmar B75W wheel excavator?

The Yanmar B75W has a transport length of 5.21 meters, a transport width of 2.19 meters, and a transport height of 3.6 meters.

What is the travel speed of the Yanmar B75W wheel excavator?

The Yanmar B75W wheel excavator has a travel speed of 30 km/h.

What are the excavation performance specifications of the Yanmar B75W wheel excavator?

The Yanmar B75W wheel excavator has a dredging depth of 3.43 meters and a maximum horizontal reach of 7.29 meters.

What is the tear-out force of the Yanmar B75W wheel excavator?

The Yanmar B75W wheel excavator has a tear-out force of 38 kN.

What is the bucket capacity of the Yanmar B75W wheel excavator?

The Yanmar B75W wheel excavator has a bucket capacity of 0.303 cubic meters.

How much is a Yanmar B75W Wheel excavator (2019u20132024) worth?

The residual value of the Yanmar B75W depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
