EW200E MH Volvo Excavator Specs & Dimensions - (2024 - 2026)

Weight: 22.1t – Standard tyres: 10,00-20 – Boom: VA – Outrigger stabilisers: 42/4-fold – Transport length: 9.55m – Transport width…

Weight: 22.1t – Standard tyres: 10,00-20 – Boom: VA – Outrigger stabilisers: 42/4-fold – Transport length: 9.55m – Transport width: 2.75m

Check out detailed dimensions, specifications, information and technical data for Volvo EW200E MH excavator manufactured between 2024 - 2026. Get more in-depth insight with Volvo EW200E MH digger specifications. See information, like: Weight: 22.1t – Standard tyres: 10,00-20 – Boom: VA – Outrigger stabilisers: 42/4-fold – Transport length: 9.55m – Transport width: 2.75m and more.

Wheel Excavators Volvo EW200E MH
Wheel Excavators Volvo EW200E MH
Wheel Excavators Volvo EW200E MH
Wheel Excavators Volvo EW200E MH
Wheel Excavators Volvo EW200E MH
Wheel Excavators Volvo EW200E MH
Wheel Excavators Volvo EW200E MH
Wheel Excavators Volvo EW200E MH
Wheel Excavators Volvo EW200E MH
Wheel Excavators Volvo EW200E MH

Visit Volvo live at

Technical specs - EW200E MH Volvo

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
22.1 t
Standard tyres
10,00-20
Boom
VA
Outrigger stabilisers
4 2/4-fold
Transport length
9.55 m
Transport width
2.75 m
Transport height
3.24 m
Max. Reach horizontal
10.5 m
Dredging depth
9 m
Dipper length
3.5 m
Travel speed
19 km/h
Model series
EW
Engine manuf.
Volvo
Engine type
D6J
Engine power
126 kW
Displacement
5.7 l
Revolutions at max torque
1800 rpm
Max. torque
850/1350 Nm
No. of cylinders
6
Cylinder bore x stroke
98x126 mm
Emission level
V

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., tear-out force, bucket width, turning radius inside, turning radius outside, dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Track guidance
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Volvo EW200E MH FAQ

When was the Volvo EW200E MH manufactured?

The Volvo EW200E MH was first produced in 2024.

How much does the Volvo EW200E MH wheel excavator weigh?

The Volvo EW200E MH wheel excavator weighs 22.1 tons.

What are the transport dimensions of the Volvo EW200E MH wheel excavator?

The Volvo EW200E MH has a transport length of 9.55 meters, a transport width of 2.75 meters, and a transport height of 3.24 meters.

What is the travel speed of the Volvo EW200E MH wheel excavator?

The Volvo EW200E MH has a travel speed of 19 km/h.

What are the undercarriage specifications of the Volvo EW200E MH wheel excavator?

The Volvo EW200E MH is equipped with standard tyres size 10.00-20 and has 4 outrigger stabilisers.

What are the excavation performance specifications of the Volvo EW200E MH wheel excavator?

The Volvo EW200E MH has a dredging depth of 9 meters, a maximum horizontal reach of 10.5 meters, features an adjustable boom, and has a dipper length of 3.5 meters.

How much is a Volvo EW200E MH Wheel excavator (2024u20132025) worth?

The residual value of the Volvo EW200E MH depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
