9MWR Mecalac Excavator Specs & Dimensions - (2021 - 2026)

Weight: 7.9t – Standard tyres: 365/70-18 – Bucket capacity: 0.355m³ – Boom: VA – Outrigger stabilisers: 22/4-fold – Transport leng…

Weight: 7.9t – Standard tyres: 365/70-18 – Bucket capacity: 0.355m³ – Boom: VA – Outrigger stabilisers: 22/4-fold – Transport length: 4.42m

Check out detailed dimensions, specifications, information and technical data for Mecalac 9MWR excavator manufactured between 2021 - 2026. Get more in-depth insight with Mecalac 9MWR digger specifications. See information, like: Weight: 7.9t – Standard tyres: 365/70-18 – Bucket capacity: 0.355m³ – Boom: VA – Outrigger stabilisers: 22/4-fold – Transport length: 4.42m and more.

9MWR

Years of manufacture: 2021—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 9MWR Mecalac

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 7.9 t

Standard tyres: 365/70-18

Bucket capacity: 0.355 m³

Boom: VA

Outrigger stabilisers: 2 2/4-fold

Transport length: 4.42 m

Transport width: 2.31 m

Transport height: 2.83 m

Max. Reach horizontal: 6.7 m

Dredging depth: 3.5 m

Tear-out force: 28 kN

Bucket width: 0.9 m

Turning radius outside: 3.56 m

Travel speed: 20 km/h

Model series: MWR

Engine manuf.: Deutz

Engine type: TCD2.9 L4

Engine power: 55.4 kW

Displacement: 2.9 l

Revolutions at max torque: 2300 rpm

Max. torque: 300/1600 Nm

No. of cylinders: 4

Cylinder bore x stroke: 92x110 mm

Emission level: EU V

More technical details, like: bucket capacity min., bucket capacity max., dipper length, turning radius inside, dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter: Yes
Blade: Yes
Cabin adjustment: No
Overload alert: Yes
Material Handling Excavator: No
Track guidance: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Mecalac 9MWR FAQ

When was the Mecalac 9MWR manufactured?

The Mecalac 9MWR was first produced in 2021.

How much does the Mecalac 9MWR wheel excavator weigh?

The Mecalac 9MWR wheel excavator weighs 7.9 tons.

What are the transport dimensions of the Mecalac 9MWR wheel excavator?

The Mecalac 9MWR has a transport length of 4.42 meters, a transport width of 2.31 meters, and a transport height of 2.83 meters.

What is the travel speed of the Mecalac 9MWR wheel excavator?

The Mecalac 9MWR has a travel speed of 20 km/h.

What are the undercarriage specifications of the Mecalac 9MWR wheel excavator?

The Mecalac 9MWR wheel excavator has standard tyres sized 365/70-18 and features 2 outrigger stabilisers.

What is the turning radius of the Mecalac 9MWR wheel excavator?

The Mecalac 9MWR has an outside turning radius of 3.56 meters.

What are the excavation performance specifications of the Mecalac 9MWR wheel excavator?

The Mecalac 9MWR has a dredging depth of 3.5 meters, a maximum horizontal reach of 6.7 meters, and features an adjustable boom.

What are the power ratings of the Mecalac 9MWR wheel excavator?

The source data does not provide power ratings for the Mecalac 9MWR wheel excavator.

What are the specifications of the primary work tool bucket on the Mecalac 9MWR wheel excavator?

The primary work tool bucket of the Mecalac 9MWR has a capacity of 0.355 cubic meters and a width of 0.9 meters.
