14 MXT Mecalac Excavator Specs & Dimensions - (1996 - 2002)

Mecalac is the manufacturer of the wheel excavator model 14 MXT. Find and download detailed specs and data sheets for this machine…

Mecalac is the manufacturer of the wheel excavator model 14 MXT. Find and download detailed specs and data sheets for this machine here.

The Mecalac 14 MXT is a 13.3t machine with Cummins engine which powers this model with up to 82kW or 109 horse power. The 14 MXT is categorised in the smallest machine segment in the wheel excavators category. The 14 MXT’s size is 2.49m x 5.96m x 3.45m. The bucket of 14 MXT has a capacity of 0,5m³ which is average for this type of machine.

The 14 MXT is manufactured and distributed with Overload alert. It does not include Aircondition, Material Handling Excavator and Quick hitch mech.. There are more detailed specifications and machine descriptions available in the original Mecalac 14 MXT specs data sheet.

This model can be acquired for a list price between €124000 and €157000. Production of the 14 MXT stopped in 2002. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

At present, 2 other wheel excavators, which range from 9.7t up to 13.3t are produced by Mecalac. Of these, 714 MW e and also 12 MTX are the most frequently visited on LECTURA Specs. Want more detailed specifications? Download the latest Mecalac 14 MXT specs data sheet on LECTURA Specs today!

Wheel Excavators Mecalac 14 MXT

Technical specs - 14 MXT Mecalac

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
13.3 t
Standard tyres
18x22.5
Bucket capacity
0.5 m³
Boom
VA
Outrigger stabilisers
2 2/4-fold
Transport length
5.96 m
Transport width
2.49 m
Transport height
3.45 m
Dredging depth
4.7 m
Tear-out force
71 kN
Model series
MXT
Engine manuf.
Cummins
Engine type
4BTA3.9C
Engine power
82 kW
Displacement
3.9 l
Revolutions at max torque
2200 rpm

More technical details, like: bucket capacity min., bucket capacity max., max. reach horizontal, bucket width, dipper length, turning radius inside, turning radius outside, travel speed, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Blade
No
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
No
Track guidance
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Mecalac 14 MXT FAQ

When was the Mecalac 14 MXT manufactured?

The Mecalac 14 MXT was manufactured from 1996 to 2002.

How much does the Mecalac 14 MXT wheel excavator weigh?

The Mecalac 14 MXT wheel excavator weighs 13.3 tons.

What are the transport dimensions of the Mecalac 14 MXT wheel excavator?

The Mecalac 14 MXT has a transport length of 5.96 meters, a transport width of 2.49 meters, and a transport height of 3.45 meters.

What are the undercarriage specifications of the Mecalac 14 MXT wheel excavator?

The Mecalac 14 MXT wheel excavator has standard tyres sized 18x22.5 and features 2 outrigger stabilisers.

What are the excavation performance specifications of the Mecalac 14 MXT wheel excavator?

The Mecalac 14 MXT has an adjustable boom and a dredging depth of 4.7 meters.

What is the tear-out force of the Mecalac 14 MXT wheel excavator?

The Mecalac 14 MXT wheel excavator has a tear-out force of 71 kN.

What is the bucket capacity of the Mecalac 14 MXT wheel excavator?

The Mecalac 14 MXT wheel excavator has a bucket capacity of 0.5 cubic meters.

How much is a Mecalac 14 MXT Wheel excavator (1996u20132002) worth?

The residual value of the Mecalac 14 MXT depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
