Technical specs - HW210A Hyundai

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
21.08 t
Standard tyres
10.00-20 14 PR
Bucket capacity
0.92 m³
Bucket capacity min.
0.8 m³
Bucket capacity max.
1.34 m³
Boom
MB
Outrigger stabilisers
4 2/4-fold
Transport length
9.54 m
Transport width
2.53 m
Transport height
3.65 m
Max. Reach horizontal
9.76 m
Dredging depth
6.21 m
Tear-out force
123 kN
Bucket width
1.19 m
Dipper length
2.7 m
Travel speed
38 km/h
Engine manuf.
Cummins
Engine type
B6.7
Engine power
129 kW
Displacement
6.7 l
Revolutions at max torque
2200 rpm
Max. torque
881/1300 Nm
No. of cylinders
6
Cylinder bore x stroke
107x124 mm
Emission level
V

More technical details, like: turning radius inside, turning radius outside, model series, dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Blade
Yes
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
No
Track guidance
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Hyundai HW210A FAQ

When was the Hyundai HW210A manufactured?

The Hyundai HW210A was first produced in 2021.

How much does the Hyundai HW210A wheel excavator weigh?

The Hyundai HW210A wheel excavator weighs 21.08 tons.

What are the transport dimensions of the Hyundai HW210A wheel excavator?

The Hyundai HW210A has a transport length of 9.54 meters, a transport width of 2.53 meters, and a transport height of 3.65 meters.

What is the travel speed of the Hyundai HW210A wheel excavator?

The Hyundai HW210A has a travel speed of 38 km/h.

What are the undercarriage specifications of the Hyundai HW210A wheel excavator?

The Hyundai HW210A has standard tyres sized 10.00-20 14 PR and 4 outrigger stabilisers (2/4-fold).

What are the excavation performance specifications of the Hyundai HW210A wheel excavator?

The Hyundai HW210A has a dredging depth of 6.21 meters, a maximum horizontal reach of 9.76 meters, features a monobloc boom, and has a dipper length of 2.7 meters.

What is the tear-out force of the Hyundai HW210A?

The Hyundai HW210A has a tear-out force of 123 kN.

What are the specifications of the bucket on the Hyundai HW210A wheel excavator?

The Hyundai HW210A wheel excavator has a bucket with a capacity ranging from 0.8 to 1.34 cubic meters, a standard capacity of 0.92 cubic meters, and a bucket width of 1.19 meters.
