Technical specs - HMK 210 W Hidromek

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
22.45 t
Standard tyres
11.00-20 (16Pr)
Bucket capacity
0.9 m³
Boom
MB
Outrigger stabilisers
2/4 2/4-fold
Transport length
9.51 m
Transport width
2.5 m
Transport height
3.22 m
Max. Reach horizontal
9.17 m
Dredging depth
5.76 m
Tear-out force
155.9 kN
Bucket width
1.11 m
Dipper length
2.4 m
Travel speed
31 km/h
Model series
HMK
Engine manuf.
Isuzu
Engine type
AR-4HK1X
Engine power
128 kW
Displacement
5.193 l
Revolutions at max torque
2000 rpm
Max. torque
670/1600 Nm
No. of cylinders
4
Cylinder bore x stroke
115x125 mm
Emission level
V

More technical details, like: bucket capacity min., bucket capacity max., turning radius inside, turning radius outside, dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Blade
Yes
Cabin adjustment
Yes
Overload alert
Yes
Material Handling Excavator
Yes
Track guidance
No
Aircondition
Yes
Quick hitch hydr.
Yes
Quick hitch mech.
No

Download datasheets (PDF)

Hidromek HMK 210 W FAQ

When was the Hidromek HMK 210 W manufactured?

The Hidromek HMK 210 W was first produced in 2020.

How much does the Hidromek HMK 210 W weigh?

The Hidromek HMK 210 W weighs 22.45 tons.

What are the transport dimensions of the Hidromek HMK 210 W wheel excavator?

The Hidromek HMK 210 W has a transport length of 9.51 meters, a transport width of 2.5 meters, and a transport height of 3.22 meters.

What is the travel speed of the Hidromek HMK 210 W wheel excavator?

The Hidromek HMK 210 W has a travel speed of 31 km/h.

What are the undercarriage specifications of the Hidromek HMK 210 W wheel excavator?

The Hidromek HMK 210 W is equipped with 11.00-20 (16Pr) standard tyres and features 2/4-fold outrigger stabilisers.

What are the excavation performance specifications of the Hidromek HMK 210 W wheel excavator?

The Hidromek HMK 210 W has a dredging depth of 5.76 meters, a maximum horizontal reach of 9.17 meters, features a monobloc boom, and has a dipper length of 2.4 meters.

What is the tear-out force of the Hidromek HMK 210 W wheel excavator?

The Hidromek HMK 210 W has a tear-out force of 155.9 kN.

What are the bucket specifications of the Hidromek HMK 210 W wheel excavator?

The Hidromek HMK 210 W has a bucket capacity of 0.9 cubic meters and a bucket width of 1.11 meters.

How much is a Hidromek HMK 210 W Wheel excavator (2020u20132025) worth?

The residual value of the Hidromek HMK 210 W depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
