WX210E Case Excavator Specs & Dimensions - (2024 - 2026)

Weight: 21.18t – Standard tyres: 10.00-20 – Bucket capacity: 0.8m³ – Bucket capacity min.: 0.48m³ – Bucket capacity max.: 1.22m³ –…

Weight: 21.18t – Standard tyres: 10.00-20 – Bucket capacity: 0.8m³ – Bucket capacity min.: 0.48m³ – Bucket capacity max.: 1.22m³ – Boom: MB

Check out detailed dimensions, specifications, information and technical data for Case WX210E excavator manufactured between 2024 - 2026. Get more in-depth insight with Case WX210E digger specifications. See information, like: Weight: 21.18t – Standard tyres: 10.00-20 – Bucket capacity: 0.8m³ – Bucket capacity min.: 0.48m³ – Bucket capacity max.: 1.22m³ – Boom: MB and more.

Wheel Excavators Case WX210E

Technical specs - WX210E Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
21.18 t
Standard tyres
10.00-20
Bucket capacity
0.8 m³
Bucket capacity min.
0.48 m³
Bucket capacity max.
1.22 m³
Boom
MB
Outrigger stabilisers
2/4 2/4-fold
Transport length
9.57 m
Transport width
2.53 m
Transport height
3.26 m
Max. Reach horizontal
9.76 m
Dredging depth
6.21 m
Tear-out force
164 kN
Dipper length
2.7 m
Turning radius inside
6.7 m
Travel speed
38 km/h
Model series
E
Engine manuf.
Cummins
Engine type
B6.7
Engine power
127 kW
Displacement
6.7 l
Revolutions at max torque
1300 rpm
Max. torque
881 Nm
No. of cylinders
6
Cylinder bore x stroke
107x124 mm
Emission level
EU V

More technical details, like: bucket width, turning radius outside, dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Blade
Yes
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
No
Track guidance
No
Aircondition
Yes
Quick hitch hydr.
Yes
Quick hitch mech.
No

Case WX210E FAQ

When was the Case WX210E manufactured?

The Case WX210E was first produced in 2024.

How much does the Case WX210E wheel excavator weigh?

The Case WX210E wheel excavator weighs 21.18 tons.

What are the transport dimensions of the Case WX210E wheel excavator?

The Case WX210E has a transport length of 9.57 meters, a transport width of 2.53 meters, and a transport height of 3.26 meters.

What is the travel speed of the Case WX210E wheel excavator?

The Case WX210E has a travel speed of 38 km/h.

What are the undercarriage specifications of the Case WX210E wheel excavator?

The Case WX210E wheel excavator is equipped with 10.00-20 standard tyres and features 2/4-fold outrigger stabilisers.

What is the inside turning radius of the Case WX210E wheel excavator?

The Case WX210E has an inside turning radius of 6.7 meters.

What are the excavation performance specifications of the Case WX210E wheel excavator?

The Case WX210E has a dredging depth of 6.21 meters, a maximum horizontal reach of 9.76 meters, features a monobloc boom, and has a dipper length of 2.7 meters.

What is the tear-out force of the Case WX210E wheel excavator?

The Case WX210E wheel excavator has a tear-out force of 164 kN.

What are the bucket capacity specifications of the Case WX210E wheel excavator?

The Case WX210E wheel excavator has a bucket capacity of 0.8 mu00b3, with a maximum capacity of 1.22 mu00b3 and a minimum capacity of 0.48 mu00b3.

How much is a Case WX210E Wheel excavator (2024u20132025) worth?

The residual value of the Case WX210E depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
