588 PL Case Poclain Excavator Specs & Dimensions - (1997 - 2000)

Manufactured by Case Poclain, this is the 588 PL wheel excavator. Find and download detailed specs and data sheets for this machin…

Manufactured by Case Poclain, this is the 588 PL wheel excavator. Find and download detailed specs and data sheets for this machine here.

This wheel excavator is built to provide up to 65kW or 87 horse power, delivered from its powerful case engine to the 12.7t 588 PL machine. This Case Poclain wheel excavator belongs to the smallest machine segment in the wheel excavators category. The model's dimensions are 7.5m x 2.49m x 3.21m. The bucket capacity of 588 PL is 0,6m³, which is above average for this type of machine.

It has been sold without air Blade, Overload alert and Quick hitch mech. As of 2000. There are more detailed specifications and machine descriptions available in the original Case Poclain 588 PL specs data sheet.

The production stopped in 2000, where this 588 PL was available at a new list price between €103000 and €131000. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

Case Poclain currently produces other wheel excavators, which range from up to - the most visited on LECTURA Specs are. Want more detailed specifications? Download the latest Case Poclain 588 PL specs data sheet on LECTURA Specs today!

Wheel Excavators Case Poclain 588 PL

Technical specs - 588 PL Case Poclain

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
12.7 t
Standard tyres
9.00-20
Bucket capacity
0.6 m³
Transport length
7.5 m
Transport width
2.49 m
Transport height
3.21 m
Model series
PL
Engine manuf.
Case
Engine type
4T 390
Engine power
65 kW

More technical details, like: bucket capacity min., bucket capacity max., boom, outrigger stabilisers, max. reach horizontal, dredging depth, tear-out force, bucket width, dipper length, turning radius inside, turning radius outside, travel speed...

More technical details, like: bucket capacity min., bucket capacity max., boom, outrigger stabilisers, max. reach horizontal, dredging depth, tear-out force, bucket width, dipper length, turning radius inside, turning radius outside, travel speed, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level, dipper length - standard, engine manufacturer, engine model, aspiration, engine output - net, engine output - gross, number of track rollers - each side, track shoe width, transport length mono boom, transport height - maximum, track length on ground, tailswing radius, zero tailswing?, ground clearance, heaped bucket capacity - standard, bucket capacity - smallest, bucket capacity - largest, overall bucket width - standard, overall bucket width - smallest, overall bucket width - largest, width over fixed tracks, track gauge - standard, ground level reach - mono boom, dig height - mono boom, dump height - mono boom, dig depth - mono boom, mono boom - size, standard dipper, longest dipper, fuel tank, hydraulic tank, ground bearing pressure, dipper tearout, bucket breakout, end lift - max reach, side lift - max reach, main pump, number of main pumps, total flow, boom pressure, operating weight are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Track guidance
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Case Poclain 588 PL FAQ

When was the Case Poclain 588 PL manufactured?

The Case Poclain 588 PL was manufactured from 1997 to 2000.

How much does the Case Poclain 588 PL wheel excavator weigh?

The Case Poclain 588 PL wheel excavator weighs 12.7 tons.

What are the transport dimensions of the Case Poclain 588 PL wheel excavator?

The Case Poclain 588 PL has a transport length of 7.5 meters, a transport width of 2.49 meters, and a transport height of 3.21 meters.

What are the undercarriage specifications of the Case Poclain 588 PL wheel excavator?

The Case Poclain 588 PL is equipped with standard tyres sized 9.00-20.

What is the bucket capacity of the Case Poclain 588 PL wheel excavator?

The bucket capacity of the Case Poclain 588 PL wheel excavator is 0.6 cubic meters.

How much is a Case Poclain 588 PL Wheel excavator (1997u20132000) worth?

The residual value of the Case Poclain 588 PL depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
