1088 P 4A Case Poclain Excavator Specs & Dimensions - (1988 - 1993)

Case Poclain is the manufacturer of the wheel excavator model 1088 P 4A. Find and download detailed specs and data sheets for this…

Case Poclain is the manufacturer of the wheel excavator model 1088 P 4A. Find and download detailed specs and data sheets for this machine here.

This wheel excavator is built to provide up to 95kW or 127 horse power, delivered from its powerful case engine to the 21t 1088 P 4A machine. The 1088 P 4A is categorised in the biggest machine segment in the wheel excavators category. The model's dimensions are 9.25m x 2.5m x 3.38m. The bucket of 1088 P 4A has a capacity of 1,15m³ which is average for this type of machine.

It does not include Overload alert, Track guidance and Blade. There are more detailed specifications and machine descriptions available in the original Case Poclain 1088 P 4A specs data sheet.

The production stopped in 1993, where this 1088 P 4A was available at a new list price between €190000 and €241000. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

Case Poclain currently produces other wheel excavators, which range from up to - the most visited on LECTURA Specs are. Want more detailed specifications? Download the latest Case Poclain 1088 P 4A specs data sheet on LECTURA Specs today!

Wheel Excavators Case Poclain 1088 P 4A

Technical specs - 1088 P 4A Case Poclain

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
21 t
Standard tyres
11.00-20
Bucket capacity
1.15 m³
Transport length
9.25 m
Transport width
2.5 m
Transport height
3.38 m
Model series
P
Engine manuf.
Case
Engine type
6T 590
Engine power
95 kW

More technical details, like: bucket capacity min., bucket capacity max., boom, outrigger stabilisers, max. reach horizontal, dredging depth, tear-out force, bucket width, dipper length, turning radius inside, turning radius outside, travel speed...

More technical details, like: bucket capacity min., bucket capacity max., boom, outrigger stabilisers, max. reach horizontal, dredging depth, tear-out force, bucket width, dipper length, turning radius inside, turning radius outside, travel speed, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Track guidance
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Case Poclain 1088 P 4A FAQ

When was the Case Poclain 1088 P 4A manufactured?

The Case Poclain 1088 P 4A was manufactured from 1988 to 1993.

How much does the Case Poclain 1088 P 4A weigh?

The Case Poclain 1088 P 4A weighs 21 tons.

What are the transport dimensions of the Case Poclain 1088 P 4A wheel excavator?

The Case Poclain 1088 P 4A has a transport length of 9.25 meters, a transport width of 2.5 meters, and a transport height of 3.38 meters.

What are the undercarriage specifications of the Case Poclain 1088 P 4A?

The Case Poclain 1088 P 4A is equipped with standard tyres sized 11.00-20.

What is the bucket capacity of the Case Poclain 1088 P 4A wheel excavator?

The bucket capacity of the Case Poclain 1088 P 4A is 1.15 cubic meters.

How much is a Case Poclain 1088 P 4A Wheel excavator (1988u20131993) worth?

The residual value of the Case Poclain 1088 P 4A depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
