B75W Zirkular Yanmar Excavator Specs & Dimensions - (2022 - 2026)

Weight: 7.6t – Standard tyres: 8.25-20, 12 PR Zwillingsbereifung – Transport length: 6.49m – Transport width: 2.19m – Transport he…

Weight: 7.6t – Standard tyres: 8.25-20, 12 PR Zwillingsbereifung – Transport length: 6.49m – Transport width: 2.19m – Transport height: 2.935m – Max. Reach horizontal: 7.18m

Check out detailed dimensions, specifications, information and technical data for Yanmar B75W Zirkular excavator manufactured between 2022 - 2026. Get more in-depth insight with Yanmar B75W Zirkular digger specifications. See information, like: Weight: 7.6t – Standard tyres: 8.25-20, 12 PR Zwillingsbereifung – Transport length: 6.49m – Transport width: 2.19m – Transport height: 2.935m – Max. Reach horizontal: 7.18m and more.

Wheel Excavators Yanmar B75W Zirkular

Visit Yanmar live at

Technical specs - B75W Zirkular Yanmar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
7.6 t
Standard tyres
8.25-20, 12 PR Zwillingsbereifung
Transport length
6.49 m
Transport width
2.19 m
Transport height
2.935 m
Max. Reach horizontal
7.18 m
Dredging depth
4.04 m
Tear-out force
38 kN
Turning radius outside
6.45 m
Travel speed
36 km/h
Model series
B
Engine manuf.
Yanmar
Engine type
4TNV98CT
Engine power
53.7 kW
Displacement
3.319 l
Revolutions at max torque
2300 rpm
Max. torque
308/1365 Nm
No. of cylinders
4
Emission level
V

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., boom, outrigger stabilisers, bucket width, dipper length, turning radius inside, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, FOPS, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Track guidance
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Yanmar B75W Zirkular FAQ

When was the Yanmar B75W Zirkular manufactured?

The Yanmar B75W Zirkular was first produced in 2024.

How much does the Yanmar B75W Zirkular weigh?

The Yanmar B75W Zirkular weighs 7.6 tons.

What are the transport dimensions of the Yanmar B75W Zirkular wheel excavator?

The Yanmar B75W Zirkular has a transport length of 6.49 meters, a transport width of 2.19 meters, and a transport height of 2.935 meters.

What is the travel speed of the Yanmar B75W Zirkular wheel excavator?

The Yanmar B75W Zirkular has a travel speed of 36 km/h.

What are the undercarriage tyre specifications of the Yanmar B75W Zirkular wheel excavator?

The Yanmar B75W Zirkular is equipped with standard tyres sized 8.25-20, 12 PR Zwillingsbereifung.

What is the outside turning radius of the Yanmar B75W Zirkular wheel excavator?

The Yanmar B75W Zirkular has an outside turning radius of 6.45 meters.

What are the excavation performance specifications of the Yanmar B75W Zirkular wheel excavator?

The Yanmar B75W Zirkular has a dredging depth of 4.04 meters and a maximum horizontal reach of 7.18 meters.

What is the tear-out force of the Yanmar B75W Zirkular?

The Yanmar B75W Zirkular has a tear-out force of 38 kN.

How much is a Yanmar B75W Zirkular Wheel excavator (2024u20132025) worth?

The residual value of the Yanmar B75W Zirkular depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
