8025 ZTS JCB excavator specs & dimensions (2006 - 2020)

Model rating: 7,67 / 10

JCB 8025 ZTS is a Mini Excavator manufactured from 2006 to 2020, with a weight of 2.81 t. It features a track width of 250 mm, a t…

JCB 8025 ZTS is a Mini Excavator manufactured from 2006 to 2020, with a weight of 2.81 t. It features a track width of 250 mm, a transport length of 4.28 m, a transport width of 1.5 m, and a transport height of 2.43 m. The machine has a tear-out force of 24 kN, a dredging depth of 2.83 m, and a maximum horizontal reach of 4.69 m. The bucket capacity is 0.1 m³. Special equipment includes a blade and rubber tracks.

Visit JCB live at

8025 ZTS

Years of manufacture: 2006—2020

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Reviews
Transport
Events
News

Technical specs - 8025 ZTS JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.81 t

Transport length: 4.28 m

Transport width: 1.5 m

Transport height: 2.43 m

Bucket capacity: 0.1 m³

Track width: 250 mm

Driver protection: Kb

Max. Reach horizontal: 4.69 m

Dredging depth: 2.83 m

Tear-out force: 24 kN

Engine manuf.: Perkins

Engine type: 403D-15

Engine power: 20 kW

Displacement: 1.496 l

Revolutions at max torque: 1600 rpm

Max. torque: 92 Nm

Emission level: III A

More technical details, like: bucket capacity min., bucket capacity max., bucket width, standard tyres, model series, dimension lxwxh, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment: No
Rubber track: Yes
Blade: Yes
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

JCB 8025 ZTS FAQ

When was the JCB 8025 ZTS manufactured?

The JCB 8025 ZTS was manufactured from 2006 to 2020.

How much does the JCB 8025 ZTS weigh?

The JCB 8025 ZTS weighs 2.81 tons.

What are the transport dimensions of the JCB 8025 ZTS mini excavator?

The JCB 8025 ZTS has a transport length of 4.28 meters, a transport width of 1.5 meters, and a transport height of 2.43 meters.

What is the track width of the JCB 8025 ZTS mini excavator?

The JCB 8025 ZTS mini excavator has a track width of 250 mm.

What is the excavation performance of the JCB 8025 ZTS mini excavator?

The JCB 8025 ZTS mini excavator has a dredging depth of 2.83 meters and a maximum horizontal reach of 4.69 meters.

What is the tear-out force of the JCB 8025 ZTS mini excavator?

The JCB 8025 ZTS mini excavator has a tear-out force of 24 kN.

What is the bucket capacity of the JCB 8025 ZTS mini excavator?

The bucket capacity of the JCB 8025 ZTS mini excavator is 0.1 cubic meters.

What operator safety features does the JCB 8025 ZTS have?

The JCB 8025 ZTS has a cabin for driver protection.

How much is a JCB 8025 ZTS Mini excavator (2006u20132020) worth?

The residual value of the JCB 8025 ZTS depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Reviews

Model rating: 7,67 / 10

JCB 8025 ZTS user from New Caledonia

It's a good machine

JCB 8025 ZTS user from Germany

It is easy to use, easy to transport, the engine is quiet.

JCB 8025 ZTS overview

Dimensions and weight

Machine Model		8025 ZTS	8030 ZTS	8035 ZTS
		ft-in (mm)	ft-in (mm)	ft-in (mm)
G Ground Clearance	ft-in (mm)	1-0 (300)	1-0 (300)	1-0 (300)
H Track Gauge	ft-in (mm)	4-1¼ (1252)	4-5 (1346)	4-9 (1450)
I Width Over Tracks	ft-in (mm)	4-11 (1502)	5-5 (1652)	5-9 (1750)
J Transport Length	ft-in (mm)	14-0½ (4280)	14-0¾ (4287)	14-8 (4462)
K Transport Height	ft-in (mm)	8-1¼ (2470)	8-1¼ (2470)	8-1½ (2487)
L Track Height	ft-in (mm)	1-6 (455)	1-7½ (500)	1-6 (470)

Machine Model		8025 ZTS	8030 ZTS	8035 ZTS
		ft-in (mm)	ft-in (mm)	ft-in (mm)
A Sprocket Idler Centers	ft-in (mm)	4-8¾ (1440)	5-3 (1597)	5-7 (1707)
B Undercarriage Overall Length	ft-in (mm)	6-2½ (1895)	6-8¾ (2052)	7-2 (2176)
C Kingpost Clearance	ft-in (mm)	2-0¼ (615)	2-0¼ (615)	2-0 (600)
D Tailswing Radius	ft-in (mm)	3-5½ (750)	3-7½ (800)	2-9½ (862)
E Overall Width of Superstructure	ft-in (mm)	5-1 (1550)	5-5 (1650)	5-5 (1656)
F Height Over Cab	ft-in (mm)	8-1¼ (2470)	8-1¼ (2470)	8-1 (2770)

Machine Model		8025 ZTS	8030 ZTS	8035 ZTS
Operating Weight*	lb (kg)	5919 (2685)	7092 (3217)	8049 (3651)
Transport Weight	lb (kg)	5754 (2610)	6927 (3142)	7884 (3576)
With Canopy	lb (kg)	220.5 - (100) -	220.5 - (100) -	-220.5 (-100)
With FOGS Guard	lb (kg)	+ 79 + (36)	+ 79 + (36)	+ 79 + (36)
With Steel Tracks	lb (kg)	+ 132 + (60)	+ 154 + (70)	+ 154 + (70)
With Long Dozer	lb (kg)	+ 53 + (24)	N/A	N/A
With Suspension Seat	lb (kg)	+ 26.5 + (12)	N/A	N/A

Machine Model		8025 ZTS	8030 ZTS	8035 ZTS
Dipper Length	ft-in (mm)	3-71 ⁄4 (1100)	4-21 ⁄4 (1300)	5-0 (1525)
A Max Digging Reach	ft-in (mm)	15-10 (4828)	16-6 (5031)	17-10 (5436)
B Max Digging Reach on Ground	ft-in (mm)	15-41 ⁄2 (4691)	16-1 (4901)	17-5 (5315)
C Max Digging Depth – Dozer Up	ft-in (mm)	8-51 ⁄2 (2580)	9-2 (2794)	10-5 (3179)
Max Digging Depth – Dozer Down	ft-in (mm)	9-31 ⁄2 (2832)	10-23 ⁄4 (3119)	11-6 (3512)
D Max Digging Height	ft-in (mm)	14-21 ⁄2 (4333)	14-71 ⁄4 (4453)	15-1 (4601)
E Max Dump Height	ft-in (mm)	10-41 ⁄4 (3158)	10-6 (3205)	11-5 (3482)
F Max Height to Dipper Nose Pivot Pin	ft-in (mm)	12-11 ⁄2 (3700)	12-6 (3808)	13-2 (4007)
G Max Vertical Wallcut Depth	ft-in (mm)	5-03 ⁄4 (1542)	5-81 ⁄2 (1741)	7-11 ⁄4 (2165)
Min Front Swing Radius (no offset)	ft-in (mm)	6-111 ⁄2 (2125)	7-01 ⁄2 (2150)	8-2 (2492)
Min Front Swing Radius (fully offset)	ft-in (mm)	6-31 ⁄4 (1912)	6-7 (2010)	5-4 (1630)
Boom Swing Left	degrees	45	45	45
Boom Swing Right	degrees	60	60	60
Bucket Rotation	degrees	189	186	186
Dipper Rotation	degrees	118.5	119	119
Bucket Tearout	lbf (kN)	24 (5395)	28 (6295)	32 (7193)
Dipper Tearout	lbf (kN)	15 (3372)	17 (3822)	20 (4496)
Slew Speed	rpm	9.6	9.6	9.6

DOZER BLADE
Machine Model		8025 ZTS	8030 ZTS	8035 ZTS
Max Height (above ground)	ft-in (mm)	1-1½ (340)	1-4¼ (414)	1-4 (413)
Dig Depth (below ground)	ft-in (mm)	1-3½ (398)	2-0½ (622)	2-1 (629)
Approach Angle	degrees	35	24.5	24.5
Width	ft-in (mm)	5-1 (1550)	5-5 (1650)	5-8 (1734)
Height	ft-in (mm)	1-1 (335)	1-1 (335)	1-1 (326)
Reach in Front of Tracks	ft-in (mm)	1-0½ (322)	2-2¾ (681)	2-2 (668)

Tables

	8025 ZTS	8030 ZTS	8035 ZTS
Pump		2 Variable & 1 Gear	2 Variable & 1 Gear	2 Variable & 1 Gear
Nominal Output	lpm	102	102	110
Nominal Output	gal/min	26.9	26.9	29.1
Excavator/Track Main Relief	psi (bar)	3191 (220)	3553 (245)	3553 (245)
Slew Main Relief	psi (bar)	2756 (190)	2756 (190)	2756 (190)
Auxiliary Hydraulic Flow	gal (l)	15.3 (58)	15.3 (58)	18.2 (69)
Hydraulic Motors		Piston	Piston	Piston

Machine Model	8025 ZTS & 8030 ZTS	8035 ZTS
Model	403D-15	403D-17
Fuel		Diesel	Diesel
Cooling		Water Cooled	Water Cooled
Gross Power	hp (kW) @ 2200 rpm	28 (20.9)	31.6 (23.6 kW)
Net Power	hp (kW) @ 2200 rpm	26.8 (20)	30.4 (22.7 kW)
Gross Torque	lbf-ft (Nm) @ 1600 rpm	70.8 (96)	78.4 (106.3 kW)
Net Torque	lbf-ft (Nm) @ 1600 rpm	67.9 (92)	75.5 (102.4 kW)
Displacement	cid (cc)	91.3 (1496)	101.5 (1663)
Gradeability	degrees	36	36
Starter Motor	hp (kW)	2.68 (2)	2.7 (2)
Battery V (A)	12 (75)	12 (75)
Alternator A	65	65
Emission Certification	Interim Tier IV	Interim Tier IV

Machine Model		8025 ZTS \| 8030 ZTS \| 8035 ZTS
Fuel Tank	gal (l)	10.6 (40)
Engine Coolant	gal (l)	2.3 (8.5)
Engine Oil	gal (l)	1.2 (4.5)
Hydraulic System	gal (l)	18.5 (70)
Hydraulic Tank	gal (l)	11.9 (45)

Machine Model		8025 ZTS \| 8030 ZTS\| 8035 ZTS
Cab/Canopy Height	ft-in (mm)	4-113 ⁄4 (1517)
Cab/Canopy Length	ft-in (mm)	3-111 ⁄2 (1205)
Cab/Canopy Width	ft-in (mm)	3-21 ⁄2 (980)
Door Aperture Width	ft-in (mm)	1-9 (532)

Machine Model	8025 ZTS	8030 ZTS	8035 ZTS
No of Bottom Rollers		3	4	4
Track Width	in (mm)	10 (250)	12 (300)	12 (300)
Ground Bearing Pressure	psi (kg/cm2 )	4.5 (0.31)	4.8 (0.33)	5.2 (.37)
Ground Clearance	in (mm)	12 (300)	12 (300)	12 (300)
Track Tensioning		Grease	Grease	Grease
Travel Speed – Low	mph (kph)	1.5 (2.4)	1.5 (2.4)	1.5 (2.4)
Travel Speed – High	mph (kph)	2.7 (4.3)	2.7 (4.3)	2.7 (4.3)
Tractive Effort	lbf (kN)	5530 (24.6)	6137 (27.3)	7194 (32)

			Reach from Slew Center
Load Point	8 ft 2½ in (2500 mm)	9 ft 10 in (3000 mm)	11 ft 6 in (3500 mm)	13 ft 1 in (4000 mm)	Capacity at Maximum Reach
									部
Height	Dozer Up	Dozer Down		Dozer Up	Dozer Down		Dozer Up	Dozer Down		Dozer Up	Dozer Down		Dozer Up	Dozer Down
ft-in (mm)	lb	lb	lb	lb	lb	lb	lb	lb	lb	lb	lb	lb	lb	lb	lb	ft-in (mm)
6-7 (2000)				860*	1382*	646*	619	1320*	465				480	1320*	359	12-9 (3886)
4-11 (1500)	1042	2175*	780*	793	1726*	595	595	1488*	447	463	1400*	348	4646	1400*	348	13-1 (3988)
3-3 (1000)	1009	2684*	756	719	1902*	540	571	1620*	428	439	1400*	328	419	1426*	313	13-5 (4089)
1-8 (500)	926	2959*	694	712	2246*	533	571	1787*	428	472	1567*	353	472	1567*	535	13-5 (4089)
Ground Level	926	3135*	694	719	2440*	540	571	1920*	428		1620*		472	1620*	353	13-5 (4089)
-1-8 (-500)	884	2870*	663	719	2431*	540	571	1876*	428				518	1708*	388	12-0 (3658)
-3-3 (-1000)	926	2839*	694	703	2114*	527							595	1690*	447	10-10 (3302)

Machine Model		8025 ZTS	8030 ZTS	8035 ZTS
Cab / Canopy External	dB (LwA)	95	95	95

Height	Dozer Up	Dozer Down		Dozer Up	Dozer Down		Dozer Up	Dozer Down		Dozer Up	Dozer Down		Dozer Up	Dozer Down
ft-in (mm)	lb	lb	lb	lb	lb	lb	lb	lb	lb	lb	lb	lb	lb	lb	lb
6-7 (2000)				1307*	1345*	1380*	1274*	1360*	1336*	860	1373*	950	694	1314*	728
4-11 (1500)	2103*	2273*	2196*	1360	1865*	1490	1080	1664*	1151	851	1536*	913	688	1473*	694
3-3 (1000)	1764	3012*	1865	1336	2339*	1354	1025	1936*	1071	855	1883*	897	675	1567*	677
1-8 (500)	1587	3481*	1764	1177	2657*	1402	1049	2196*	1060	809	1872*	875	694	1038*	690
Ground Level	1455	3702*	1735	1166	3183*	1332	966	2350*	1065	796	1947*	851	664	1036*	1151
-1-8 (-500)	1508	3977*	1673	1224	3232*	1272	983	2480*	1047	833	2187*	860	743	1806*	743
-3-3 (-1000)	1523	3732*	1702	1100	2912*	1290	884	2463*	1060	796	2061*	880	798	1894*	849

Load Point	8 ft 2½ in (2500 mm)	9 ft 10 in (3000 mm)	11 ft 6 in (3500 mm)	13 ft 1 in (4000 mm)	Capacity at Maximum Reach
									7					山
Height	Dozer Up	Dozer Down		Dozer Up	Dozer Down		Dozer Up	Dozer Down		Dozer Up	Dozer Down		Dozer Up	Dozer Down
ft-in (mm)	lb	lb	lb	lb	lb	lb	lb	lb	lb	lb	lb	lb	lb	lb	lb	ft-in (mm)
6-7 (2000)							992	1294*	893	785		712	778	1322*		13-5 (4089)
4-11 (1500)	1832	2618*	1455*	1199	1851*	1142	943	1488*	893	778	1408*	703	703	1400*		13-8 (4166)
3-3 (1000)	1605	2790*	1439	1199	2021*	1109	926	1706*	851	752	1505*	694	668	1468*	646	14-0 (4267)
1-8 (500)	1521	3401*	1340	1148	2354*	1009	926	1909*	818	752	1644*	679	661	1534*	646	13-10 (4216)
Ground Level	1406	3374*	1314	1091	2550*	1001	910	2072*	802	745	1677*	670	712	1697*	670	13-5 (4089)
-1-8 (-500)	1327	3326*	1256	1042	2616*	983	893	2032*	802				756	1726*	712	12-8 (3861)
-3-3 (-1000)	1355	3280*	1241	1091	2781*	926							910	1869*	778	11-6 (3505)
