    JCB 8008 excavator specs (2006 - 2010)

    8,00/10 Rate this machine now!

    The 8008 mini excavator model is manufactured by JCB. Find and download detailed specs and data sheets for this machine here. ... Read more

    The 8008 mini excavator model is manufactured by JCB. Find and download detailed specs and data sheets for this machine here.

    This mini excavator is built to provide up to 9kW or 12 horse power, delivered from its powerful Perkins engine to the 0.95t 8008 machine. This JCB mini excavator belongs to the smallest machine segment in the mini excavators category. The model's dimensions are 2.68m x 0.7m x 2.31m. The bucket capacity of 8008 is 0.02m³, which is above average for this type of machine.

    Since 2006, this model has included Blade and Rubber track. It does not include Quick hitch mech., Track adaption and Aircondition. There are more detailed specifications and machine descriptions available in the original JCB 8008 specs data sheet. Available in Italian, Spanish and English, LECTURA Specs offers a free download of highly detailed specifications and machine descriptions of this model.

    The production is still going in 2017, where this 8008 is available at a new list price between €20000 and €25000. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

    The most commonly viewed JCB models of this type on LECTURA Specs are the 8018 CTS, 8014 CTS and 8026 CTS, and 19 other mini excavators, which currently range from 1.1t up to 5.4t are also available. Ranked in the LECTURA index at #62, this 8008 mini excavator has models that date from 2006 to 2017. Currently, 19 models of the 8008 mini excavator exist, at an average sale value of €8500 at 5 years of age. Want more detailed specifications? Download the latest JCB 8008 specs data sheet on LECTURA Specs today!

    Technical specs - 8008 JCB

    Specification

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

    • Weight 0.95 t
    • Transport length 2.68 m
    • Transport width 0.7 m
    • Transport height 2.31 m
    • Bucket capacity max. 0.02 m³
    • Track width 180 mm
    • Driver protection Ü
    • Max. Reach horizontal 3,11 m
    • Dredging depth 1,69 m
    • Tear-out force 4,6 kN
    • Engine manuf. Perkins
    • Engine type 403D-07
    • Engine power 9 kW
    • Displacement 0.762 l
    • Revolutions at max torque 1800 rpm
    • Max. torque 46 Nm
    • Bucket capacity ###
    • Bucket capacity min. ###
    • Bucket width ###
    • Standard tyres ###
    • Dimension lxwxh ###
    • No. of cylinders ###
    • Cylinder bore x stroke ###
    • Emission level ###

    Basic model with standard bucket

    Special equipment

    • Track adjustment
    • Rubber track
    • Blade
    • Aircondition
    • Quick hitch hydr.
    • Quick hitch mech.
