K008-3 Kubota excavator specs & dimensions (2019 - 2022)

Kubota K008-3 is a mini excavator manufactured from 2019 to 2022. It has a weight of 1 ton and a track width of 180 mm. The transp…

Kubota K008-3 is a mini excavator manufactured from 2019 to 2022. It has a weight of 1 ton and a track width of 180 mm. The transport dimensions are 2.75 m in length, 0.86 m in width, and 2.23 m in height. The machine features a tear-out force of 10 kN, a dredging depth of 1.72 m, and a maximum horizontal reach of 3.03 m. Special equipment includes a blade and rubber tracks.

K008-3

Years of manufacture: 2019—2022

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - K008-3 Kubota

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 1 t

Transport length: 2.75 m

Transport width: 0.86 m

Transport height: 2.23 m

Track width: 180 mm

Driver protection: Ü

Max. Reach horizontal: 3.03 m

Dredging depth: 1.72 m

Tear-out force: 10 kN

Model series: K

Engine manuf.: Kubota

Engine type: D722-E3

Engine power: 7.7 kW

Displacement: 0.72 l

Emission level: Tier IV

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, standard tyres, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment: No
Rubber track: Yes
Blade: Yes
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

K008-3 Kubota Specification for North America (EN)

Kubota K008-3 FAQ

When was the Kubota K008-3 manufactured?

The Kubota K008-3 was manufactured from 2019 to 2022.

How much does the Kubota K008-3 weigh?

The Kubota K008-3 weighs 1 ton.

What are the transport dimensions of the Kubota K008-3 mini excavator?

The Kubota K008-3 has a transport length of 2.75 meters, a transport width of 0.86 meters, and a transport height of 2.23 meters.

What is the track width of the Kubota K008-3 mini excavator?

The Kubota K008-3 mini excavator has a track width of 180 mm.

What are the excavation performance specifications of the Kubota K008-3 mini excavator?

The Kubota K008-3 mini excavator has a dredging depth of 1.72 meters and a maximum horizontal reach of 3.03 meters.

What is the tear-out force of the Kubota K008-3 mini excavator?

The Kubota K008-3 mini excavator has a tear-out force of 10 kN.

What operator safety feature does the Kubota K008-3 mini excavator have?

The Kubota K008-3 mini excavator is equipped with a roll-over bar for driver protection.

How much is a Kubota K008-3 Mini excavator (2019u20132022) worth?

The residual value of the Kubota K008-3 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Kubota K008-3 overview

Kubota K008-3 features overview

Fast and easy maintenance
A fully-opened bonnet and new engine layout make daily inspection and maintenance of essential components child's play. Both features now give you easy access to radiator, battery, coolant, fuel filter and two-element air

Engine / Driveline and transmission

complies with the EPA's 2008 Tier IV emissions regulations.
Allows the operator to choose between ISO or SAE control patterns. Requires approximately 5 minutes to make the minor mechanical changes.
Reliable Kubota E-TVCS engine
Super reliable and efficient reduces combustion generated by the unique three-vortex combustion system of our engine, exhaust emissions, noise and vibration.

Tyres / Tracks

Two-way lever
It is within easy reach and allows a change between the control of the blade or adjustable track width.
Adjustable width track frame
To allow passage through narrow spaces such as door openings and gates, the adjustable wide rail frame can reduce the track width of the K008-3 to 700 mm by simply operating a single lever. Also, changing blade width is as easy as removing a pin by hand.

Dimensions and weight

Model		K008-3
Type of tracks	Rubber
Engine	Model	Kubota D722-E3
Output (SAEJ 1995 gross) HP (kW)/rpm	10.3 (7.7) / 2050
Output (SAEJ 1349 net) HP (kW)/rpm	10.1 (7.5) / 2050
Displacement cu.in. (cc)	44 (719)
Dimensions	Overall length ft.in. (mm)	9'0"" (2750)"
ft.in. (mm) Overall height	7'4"" (2230)"
Overall width ft.in. (mm)	2'10"" (860) / 2'4"" (700)"
Min. ground clearance	in. (mm)	5.9"" (150)"
Hydraulic system	Pump capacity gpm. (l/min)	5.55 (21.0)
Auxiliary hydraulic flow gpm. (l/min)	5.55 (21.0)
Max. breakout force	Bucket	lbs. (kgf)	2200 (1000)
Arm	lbs. (kgf)	1010 (460)
Drive system	Travel speed		mph (km/h)	1.2 / 2.5 (2.0 / 4.0)
Max. traction force		lbs. (kgf)	1695 (770)
Tumbler distance		ft.in. (mm)	2'11"" (900)"
Crawler length ft.in. (mm)	4'0"" (1230)"
Shoe width	in. (mm)	7.1"" (180)"
Ground contact pressure	psi (kgf/cm2 )	3.55 (0.25)
Swing system	Unit swing speed	rpm	8.3
Boom swing angle	Left degree	55
Right	degree	60
Blade	Dimensions	Width	in. (mm)	2'4"" / 2'10"" (700 / 860)"
Height	in. (mm)	7.9"" (200)"
Max. lift above ground	in. (mm)	7.9"" (200)"
Max. drop below ground	in. (mm)	7.1"" (180)"
Hydraulic oil (reservoir/system)		gpm. (l/min)	3.30 / 4.49 (12.5 / 17.0)
Fuel reservoir		gpm. (l/min)	3.17 (12.0)
Operating weight
Including operator’s weight 175 lbs.		lbs.(kgf)	2200 (1000)

Max. digging height	ft.in. (mm)	9'5"" (2870)"
Max. dumping height	ft.in. (mm)	6'8"" (2035)"
Max. digging depth	ft.in. (mm)	5'8"" (1715)"
Max. vertical digging depth	ft.in. (mm)	4'6"" (1375)"
Max. digging radius	@ ground	ft.in. (mm)	9'11"" (3025)"
Max. digging radius		ft.in. (mm)	10'1"" (3075)"
Min. turning radius	W/o swing	ft.in. (mm)	3'8"" (1120)"
With swing	ft.in. (mm)	3'2"" (955)"
Min. tail turning radius		ft.in. (mm)	2'6"" (750)"

Other features

Handy toolbox
To make basic maintenance easier for you, the K008-3 is delivered completely with a toolbox conveniently located under the operator's seat.
Comfortable operator's seat
Well padded and contoured appreciate the comfort of its operator's seat, especially on long operating days.
Spacious operator's area
You will find it more convenient behind the operator levers of the K008-3. Because we have generously enlarged the space between the operating levers and the seat of the operator, extending the floor plates.

Safety

Protected bucket hoses
By running inside the dipper arm, bucket hoses are also well protected from damage.
Improved hose and boom cylinder protection
All hydraulic hoses hidden in the boom and dipper arm. With the cylinder on top of the boom, the K008-3 increases life by providing outstanding protection from damage.
Protected auxiliary hoses
By routing its auxiliary hydraulic hoses through the boom, the K008-3 no longer needs long hoses when connecting your attachments. In addition, a shorter hose length greatly reduces the risk of carry-over and damage.
