    Takeuchi TB 260 excavator specs (2014 - 2023)

    8,50/10 Rate this machine now!

    Manufactured by Takeuchi, this is the TB 260 mini excavator. Find and download detailed specs and data sheets for this machine her... Read more

    Manufactured by Takeuchi, this is the TB 260 mini excavator. Find and download detailed specs and data sheets for this machine here.

    Equipped with a powerful Yanmar engine, this TB 260 5.7t machine can provide 32.4kW or 43 horse power for the mini excavator. This Takeuchi mini excavator belongs to the biggest machine segment in the mini excavators category. The TB 260’s size is 2m x (no data) x (no data). The bucket of TB 260 has a capacity of 0.06m³ which is average for this type of machine.

    The Takeuchi TB 260 has been equipped and sold with Rubber track, Blade and Aircondition. It does not include Track adaption, Quick hitch mech. And Quick hitch hydr.. There are more detailed specifications and machine descriptions available in the original Takeuchi TB 260 specs data sheet. Download a free data sheet in French, German and English from LECTURA Specs.

    The production is still going in 2017, where this TB 260 is available at a new list price between €80000 and €102000. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

    At present, 17 other mini excavators, which range from 1.1t up to 5.6t are produced by Takeuchi. Of these, TB 240, TB 153 FR and also TB 215 R are the most frequently visited on LECTURA Specs. Having been in production from 2014 to 2017, the TB 260 mini excavator ranks in the LECTURA index at #20. Want more detailed specifications? Download the latest Takeuchi TB 260 specs data sheet on LECTURA Specs today!

    Technical specs - TB 260 Takeuchi


    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

    • Weight 5.7 t
    • Transport width 2 m
    • Bucket capacity 0.06 m³
    • Track width 400 mm
    • Driver protection Kb
    • Max. Reach horizontal 6.13 m
    • Dredging depth 3.9 m
    • Tear-out force 43 kN
    • Engine manuf. Yanmar
    • Engine type 4TNV84T
    • Engine power 32.4 kW
    • Displacement 2 l
    • Revolutions at max torque 2400 rpm

    More technical details, like: transport length, transport height, bucket capacity min., bucket capacity max., bucket width, standard tyres, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

    Basic model with standard bucket

    Special equipment

    • Track adjustment
    • Rubber track
    • Blade
    • Aircondition
    • Quick hitch hydr.
    • Quick hitch mech.
