TB216A Takeuchi excavator specs & dimensions (2013 - 2017)

Takeuchi TB216A is a mini excavator manufactured from 2013 to 2017, with a weight of 1.8 tons. It features a track width of 230 mm…

Takeuchi TB216A is a mini excavator manufactured from 2013 to 2017, with a weight of 1.8 tons. It features a track width of 230 mm and a transport width of 0.98 meters. The bucket capacity is 0.04 cubic meters. Special equipment includes a blade, rubber track, and track adjustment.

Mini Excavators Takeuchi TB216A

Technical specs - TB216A Takeuchi

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.8 t
Transport width
0.98 m
Bucket capacity
0.04 m³
Track width
230 mm
Driver protection
Kb
Max. Reach horizontal
4.03 m
Model series
TB
Engine manuf.
Yanmar
Engine type
3TNV70
Engine power
11.5 kW
Displacement
0.85 l
Revolutions at max torque
2400 rpm

More technical details, like: transport length, transport height, bucket capacity min., bucket capacity max., bucket width, standard tyres, dredging depth, tear-out force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
Yes
Rubber track
Yes
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Takeuchi TB216A FAQ

When was the Takeuchi TB216A manufactured?

The Takeuchi TB216A was manufactured from 2013 to 2017.

How much does the Takeuchi TB216A weigh?

The Takeuchi TB216A weighs 1.8 tons.

What is the transport width of the Takeuchi TB216A mini excavator?

The transport width of the Takeuchi TB216A mini excavator is 0.98 meters.

What is the track width of the Takeuchi TB216A mini excavator's undercarriage?

The Takeuchi TB216A mini excavator has a track width of 230 mm.

What is the maximum horizontal reach of the Takeuchi TB216A mini excavator?

The Takeuchi TB216A mini excavator has a maximum horizontal reach of 4.03 meters.

What is the bucket capacity of the Takeuchi TB216A mini excavator?

The bucket capacity of the Takeuchi TB216A mini excavator is 0.04 cubic meters.

What operator safety features does the Takeuchi TB216A have?

The Takeuchi TB216A has a cabin for driver protection.
