TC 50 Terex excavator specs & dimensions (2005 - 2016)

Model rating: 8,00 / 10

Terex TC 50 is a mini excavator manufactured from 2005 to 2016. It has a weight of 4.82 tons and a track width of 400 mm. The tran…

Terex TC 50 is a mini excavator manufactured from 2005 to 2016. It has a weight of 4.82 tons and a track width of 400 mm. The transport dimensions are 5.39 m in length, 1.99 m in width, and 2.55 m in height. The machine features a tear-out force of 27 kN, a dredging depth of 3.7 m, and a maximum horizontal reach of 6.22 m. The bucket width is 0.4 m, with a capacity ranging from 0.068 m³ to 0.232 m³. Special equipment includes a blade, mechanical quick hitch, and rubber tracks.

TC 50

Years of manufacture: 2005—2016

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Reviews
Transport
News

Technical specs - TC 50 Terex

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.82 t

Transport length: 5.39 m

Transport width: 1.99 m

Transport height: 2.55 m

Bucket capacity min.: 0.068 m³

Bucket capacity max.: 0.232 m³

Bucket width: 0.4 m

Track width: 400 mm

Driver protection: Kb

Max. Reach horizontal: 6.22 m

Dredging depth: 3.7 m

Tear-out force: 27 kN

Model series: TC

Engine manuf.: Yanmar

Engine type: 4TNV88

Engine power: 26.5 kW

Displacement: 2.19 l

Revolutions at max torque: 1500 rpm

More technical details, like: bucket capacity, standard tyres, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment: No
Rubber track: Yes
Blade: Yes
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: Yes

Download datasheets (PDF)

Terex TC 50 FAQ

When was the Terex TC 50 manufactured?

The Terex TC 50 was manufactured from 2005 to 2016.

How much does the Terex TC 50 weigh?

The Terex TC 50 weighs 4.82 tons.

What are the transport dimensions of the Terex TC 50 mini excavator?

The Terex TC 50 has a transport length of 5.39 meters, a transport width of 1.99 meters, and a transport height of 2.55 meters.

What is the track width of the Terex TC 50 mini excavator?

The Terex TC 50 mini excavator has a track width of 400 mm.

What are the excavation performance specifications of the Terex TC 50 mini excavator?

The Terex TC 50 mini excavator has a dredging depth of 3.7 meters and a maximum horizontal reach of 6.22 meters.

What is the tear-out force of the Terex TC 50 mini excavator?

The Terex TC 50 mini excavator has a tear-out force of 27 kN.

What are the bucket specifications of the Terex TC 50 mini excavator?

The Terex TC 50 mini excavator has a bucket width of 0.4 meters, with a maximum capacity of 0.23 cubic meters and a minimum capacity of 0.07 cubic meters.

What operator safety features does the Terex TC 50 have?

The Terex TC 50 has a cabin for driver protection.

How much is a Terex TC 50 Mini excavator (2005u20132016) worth?

The residual value of the Terex TC 50 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Reviews

Model rating: 8,00 / 10

Terex TC 50 user from South Africa

Small enough to do big jobs

Terex TC 50 user from Norway

Reliable machine in my experience,have had it for 7 years and no parts replaced yet.

Terex TC 50 overview

Hydraulics

OPTIONAL EQUIPMENT BOOM OPTIONS CRAWLER CHAIN OPTIONS HYDRAULIC SYSTEM
Monobloc boom, with extended dipper stick 1850 mm steel crawler track, 400 mm wide Rubber coated steel crawler chain 'Roadliner', 400 mm wide. Terex "Fingertip" control for work attachments on right joystick Terex ́Fingertip‘ control including second auxiliary control circuit on left joystick Second control circuit (e.g. to sort grapples) Hose break / load holding valve for boom with load warning device Hose rupture / Load-retaining valve for dipperstick Biodegradable hydraulic oil / ester base HLP 68 (Paolin)
DRIVER'S STAND
rebuild kit from ISO controls to Schaeff control elements Floating position - dozer blade Operator seat MSG 85 (comfort version), hydraulic damping, extra-high backrest, tilt adjustable armrests, longitudinal horizontal suspension, mechanical lumbar support Operator seat MSG 95 (premium version), air cushioning, extra-high backrest and tilt adjustable armrests, longitudinal horizon suspension, seat and back rest heater, pneumatic lumbar linkage.

Tyres / Tracks

Diesel exhaust cleaner Air conditioning Movement alarm incl. horn (to be deactivated on request) Work fl oohlicht, Front Anti-theft device (immobilizer) Yellow beacon Mechanical quick hold system (QAS) Quick docking system, mechanical (real Lehnhoffanlage), type MS03 Additional boom mounted working fl ow light Engine independent diesel heater with fresh air circulation and timer Front dozer blade - extra long version Working fl owlight, rear Radio kit Installation kit Rain guard Crane loader wire rope tree Canopy with work fl ow light (weight reduction: 80 kg) Electric refuel pump Special coating / stick fi lms Other optional equipment available upon request

Dimensions and weight

Transport weight (incl. QAS	without bucket)"	4820 kg
Operating weight acc. to ISO 6016 (incl. operator)	5020 kg
Total length (travel position)	3570 mm
Total height (travel position)	3895 mm
Overall width (undercarriage)	1990 mm
Total width (uppercarriage)	1850 mm
Uppercarriage tailswing	995 mm
Uppercarriage frontswing	2020 mm
Working envelope 180° / 360°	3015 / 4040 mm
Ground clearance	360 mm
Bucket digging force (ISO 6015)	31	200 N"
Stick digging force (ISO 6015)	27	000 (23	800*) N"
Ground pressure (rubber crawlers)	0.27 daN/cm2
Ground pressure (steel crawlers)	0.28 daN/cm2

Torsion-proof welded design. Crawler unit carriers in sloped design for dirt outlet. Maintenance-free crawler-type undercarriage. Idler suspension with hydraulic crawler track tensioning.
Width rubber crawlers / steel crawlers	400 mm
Tread width	1590 mm
Total length (sprocket - idler)	1920 mm
Total length (undercarriage)	2430 mm

Tables

Width x height	1990 x 400 mm
Dozer cut below ground	220 mm
Dozer lift above ground	500 mm
Slope angle	38°

Nominal voltage	12 V
Battery	12 V / 74 Ah
Generator	12 V / 50 A
Starter	12 V / 2.0 kW

Angle of articulation / lateral adjustment left	67° / 860 mm
Angle of articulation / lateral adjustment right	64° / 770 mm
FLUID CAPACITIES

Fuel tank	65 l
Hydraulic system (incl. tank 60 l)	90 l

70 60 50 40 30 20 10






0	0	20	40	60	80	100	120	140	160	180	200 220

Variable pump capacity	max. 140 l/min
Working pressure	250 bar

Hydrostatic drive	also acts as wear-resistant brake. Additional spring-loaded multi-disc brake. Internally toothed ring gear."
Swing speed 0-10 rpm
KNICKMATIK®

Automatic shift-over between speed range 1 and 2.
Gradeability	max. 60 %
Drawbar pull 1st / 2nd speed range	4280 / 2400 daN

Dipperstick 1650	mm	2.5 m	3.0 m	3.5 m	4.0 m	4.5 m	5.0 m	5.3 m
		End	Side	End	Side	End	Side	End	Side	End	Side	End	Side	End	Side
2.0 m	S	-	-	1.68	1.27	1.55	1.00	1.39	0.77	1.24	0.65	1.15	0.54	1.08	0.51
	T	-	-	1.52	1.23	1.09	0.94	0.86	0.76	0.71	0.62	0.58	0.51	0.55	0.48
1.0 m	S	3.56	1.49	2.57	1.16	2.00	0.94	1.64	0.77	1.39	0.63	1.18	0.53	1.04	0.48
	T	1.65	1.42	1.32	1.11	1.03	0.89	0.85	0.72	0.70	0.59	0.57	0.50	0.51	0.45
0 m	S	3.03	1.36	2.44	1.07	1.91	0.85	1.57	0.69	1.28	0.59	1.06	0.50	0.97	0.47
	T	1.56	1.32	1.16	1.02	0.94	0.82	0.77	0.67	0.64	0.56	0.55	0.47	0.51	0.44
