Technical specs - TB 240 Takeuchi

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
4.07 t
Transport length
5.065 m
Transport width
1.74 m
Transport height
2.49 m
Track width
350 mm
Driver protection
Kb
Max. Reach horizontal
5.28 m
Dredging depth
3.315 m
Tear-out force
30.8 kN
Model series
TB
Engine manuf.
Yanmar
Engine type
4TNV88C
Engine power
26.7 kW
Displacement
2.189 l
Revolutions at max torque
2200 rpm
Max. torque
144.9 Nm
Emission level
EU V / EPA Tier 4

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, standard tyres, dimension lxwxh, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
Yes
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Takeuchi TB 240 FAQ

When was the Takeuchi TB 240 manufactured?

The Takeuchi TB 240 was first produced in 2024.

How much does the Takeuchi TB 240 weigh?

The Takeuchi TB 240 weighs 4.07 tons.

What are the transport dimensions of the Takeuchi TB 240 mini excavator?

The Takeuchi TB 240 has a transport length of 5.065 meters, a transport width of 1.74 meters, and a transport height of 2.49 meters.

What is the track width of the Takeuchi TB 240 mini excavator?

The Takeuchi TB 240 mini excavator has a track width of 350 mm.

What is the excavation performance of the Takeuchi TB 240 mini excavator?

The Takeuchi TB 240 mini excavator has a dredging depth of 3.315 meters and a maximum horizontal reach of 5.28 meters.

What is the tear-out force of the Takeuchi TB 240 mini excavator?

The Takeuchi TB 240 mini excavator has a tear-out force of 30.8 kN. No power rating data is available for this machine in the provided source.

What operator safety and support features does the Takeuchi TB 240 have?

The Takeuchi TB 240 provides operator safety with a cabin for driver protection.
