Technical specs - TB 230 Takeuchi

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.875 t
Transport length
4.185 m
Transport width
2.525 m
Transport height
1.46 m
Track width
300 mm
Driver protection
Kb
Max. Reach horizontal
4.56 m
Dredging depth
2.68 m
Model series
TB
Engine manuf.
Yanmar
Engine type
3TNV88F
Engine power
18.2 kW
Displacement
1.642 l
Revolutions at max torque
2400 rpm
Max. torque
92,2/1440 Nm
Emission level
EU V / EPA Tier 4

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, standard tyres, tear-out force, dimension lxwxh, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
No
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Takeuchi TB 230 FAQ

When was the Takeuchi TB 230 manufactured?

The Takeuchi TB 230 was first produced in 2024.

How much does the Takeuchi TB 230 weigh?

The Takeuchi TB 230 weighs 2.875 tons.

What are the transport dimensions of the Takeuchi TB 230 mini excavator?

The Takeuchi TB 230 has a transport length of 4.185 meters, a transport width of 2.525 meters, and a transport height of 1.46 meters.

What is the track width of the Takeuchi TB 230 mini excavator?

The Takeuchi TB 230 mini excavator has a track width of 300 mm.

What are the excavation performance specifications of the Takeuchi TB 230 mini excavator?

The Takeuchi TB 230 mini excavator has a dredging depth of 2.68 meters and a maximum horizontal reach of 4.56 meters.

What operator safety features does the Takeuchi TB 230 have?

The Takeuchi TB 230 has a cabin for driver protection.

How much is a Takeuchi TB 230 Mini excavator (2024u20132025) worth?

The residual value of the Takeuchi TB 230 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
